Tovaglieri TU520 3000 mm Lathe Machine

Name: Tovaglieri TU520 3000 mm Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Tovaglieri TU520 3000 mm Lathe Machine Specification

Product Type
Heavy Duty Lathe Machine

Material
Cast Iron, Steel

Cutting Thickness
Up to 25 mm

Cutting Speed
35 - 2000 RPM

CNC Or Not
No (Conventional Lathe)

Automatic Grade
Semi-Automatic

Control System
Manual

Max. Swing Diameter
520 mm

Voltage
415 V, 3 Phase

Weight (kg)
Approx. 3900 kg

Dimension (L*W*H)
4450 mm x 1100 mm x 1450 mm

Capacity
3 Meter (3000 mm) between centers

Feature
Rigid construction, Precision ground bed, Hardened gears

Color
Blue & White

Tailstock Quill Diameter
75 mm

Tailstock Quill Travel
200 mm

Thread Cutting Range
Metric: 0.5-7 mm, Inch: 2-28 tpi

Main Motor Power
7.5 kW

Tool Post Type
4-Way

Feed Range
Longitudinal: 0.05 - 1.5 mm/rev

Spindle Nose
D1-8

Bed Width
400 mm

Chuck Diameter
400 mm

Spindle Bore
80 mm

Distance Between Centers
3000 mm

Tovaglieri TU520 3000 mm Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

Tovaglieri TU520 3000 mm Lathe Machine About

Make - Tovaglieri (Italy)

Model - TU 520

Center Height - 260 mm

Max. Length of Job - 3000 mm

Max. Job Diameter over Bed - 520 mm

Max. Job Diameter over Cross-Slide - 320 mm

Bed Width - 370 mm

Chuck Diameter - 310 mm

Max. Job Diameter in Gap - 715 mm

Spindle Speeds - 18 rpm to 1600 rpm

Spindle Bore - 51 mm

- Complete with 3-point steady.

- Operating Manual is available.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/dRhVH6PZR4E

Precision Engineering for High-Quality Turning

With its rigid construction and hardened gears, the TU520 lathe ensures stable and accurate machining. The wide bed and precision ground surfaces minimize vibrations, resulting in smoother finishes and reliable repeatability for demanding industrial applications. Operators benefit from superior build quality, contributing to extended machine life and reduced maintenance.

Versatile Performance for Diverse Applications

The Tovaglieri TU520 accommodates varied workpiece sizes and materials, thanks to its large spindle bore and capacity between centers. Its extensive feed and thread-cutting range make it suitable for producing metric and imperial threads, while the adjustable cutting speeds support both coarse and fine machining operations. This flexibility serves workshops in automotive, manufacturing, and metalworking sectors.

FAQs of Tovaglieri TU520 3000 mm Lathe Machine:

Q: How is the Tovaglieri TU520 3000 mm Lathe Machine operated?

A: The TU520 is a conventional, manually controlled lathe. Operators use mechanical controls and hand wheels to adjust spindle speed, feed rates, and cutting positions, making it straightforward to use for skilled machinists.

Q: What materials can be machined with this lathe?

A: This lathe is constructed from cast iron and steel, making it durable for machining a wide variety of metal workpieces, such as mild steel, stainless steel, and cast iron, suitable for both roughing and finishing operations.

Q: Where is the Tovaglieri TU520 typically used?

A: It is commonly employed in manufacturing plants, metalworking workshops, maintenance facilities, and by exporters and traders who require precise and reliable turning operations for medium to large components.

Q: What is the process for threading on this machine?

A: Thread cutting is achieved by selecting the desired pitch using gear settings. The TU520 offers metric threading (0.5-7 mm) and inch threading (228 tpi), providing easy adjustment for multiple standards and thread sizes.

Q: What are the benefits of the precision ground bed and hardened gears?

A: A precision ground bed ensures accuracy during machining by minimizing deflection, while hardened gears contribute to long-lasting performance and reduce wear, ensuring consistent operation over time.

Q: Can this lathe accommodate automatic features?

A: The TU520 is a semi-automatic machine. While primary controls are manual, it offers features such as a four-way tool post and automatic feed options to enhance productivity and simplify repetitive tasks.
