Universal Hydraulic Tool And Cutter Grinder

Name: Universal Hydraulic Tool And Cutter Grinder
Brand: Liberty Metal & Machines Private Limited
Price: 2500 INR
Availability: InStock

Price 2500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Universal Hydraulic Tool And Cutter Grinder Specification

Machine Type
Universal Hydraulic Tool & Cutter Grinder

Operation Type
Semi-automatic / Manual Feed

Material
Cast Iron, Mild Steel, Alloy Steel

Shape
Rectangular Base with Cylindrical Grinding Head

Length
Base length approx. 1200 mm

Features
Hydraulic Movement, Precision Slideways, High Accuracy, Adjustable Head, Multi-functional Grinding

Coating
Uncoated

Drill Bits Types
End Mills, Reamers, Drills, Form Tools

Cutting Force
Hydraulic - adjustable

Cutting Speed
3600 RPM (wheel speed)

Cutting Accuracy
±0.02 mm

Hardness
Up to 60 HRC

Tool Type
Universal Tool Grinder

Brooches Type
For broaches and similar tools

Cutter Type
Tool, Surface, and End Mill Cutters

Cutting Capacity
Tool Diameter up to 200 mm

Operate Method
Hydraulic/Electric

Diameter
Max. 200 mm (grinding wheel)

Maximum Torque
N/A (Torque not specified for grinder)

Processing Type
Tool and Cutter Grinding

Electrical Motor Power
1.5 HP / 1440 RPM

Weight
Approx. 750 kg

Coolant System
Integrated

Head Swivel Range
±90°

Blade Size
Dependent on tool attachment

Grinding Wheel Size
Max. 200 mm diameter x 20 mm width

Application
Resharpening, Cutting & Grinding of Tools

Spindle Speed
3600 RPM

Table Traverse
Longitudinal 450 mm, Cross 200 mm

About Universal Hydraulic Tool And Cutter Grinder

La Parora (Italy) make Universal Tool & Cutter Grinder in excellent working condition. The model of the machine is Beta U50 ri and it is equipped with a DRO. The technical details are as follows -

Make - La Parora (Italy)

Model - Beta U50 ri

Clamping Surface - 950 mm x 130 mm

Longitudinal Travel - 500 mm

Cross Travel - 220 mm

Vertical Travel - 225 mm

Spindle Speeds - 3000 rpm & 6000 rpm

Angle of Rotation of Wheel-Head - 90 to -90

Angle of Tilting of Wheel-Head - +20 to -20

Type - Hydraulic

- Equipped with 2-Axis DRO on Cross & Vertical Travels.

- With Internal Grinding Spindle, Work-Heads, Tail-stock etc.

- With lots of other accessories like collet sets, magnet, spare grinding wheels, etc.

- Complete with Dust Collector, Wheel Balancing Stand, Index-Plates etc.

- Machine is in excellent working condition.

Video link - https://youtu.be/rAJYLdAGfxY

Precision Grinding for Diverse Tools

Engineered to deliver high accuracy with a cutting precision of 0.02 mm, this grinder supports a wide range of tool types, including end mills, reamers, drills, form tools, and broaches. Its adjustable head and precision slideways make it suitable for complex grinding operations.

Advanced Hydraulic and Electric Operation

Equipped with hydraulic movement and manual feed options, the grinder allows users to select optimal operation modes. The integrated hydraulic system enables adjustable cutting force, facilitating smooth and reliable tool and cutter grinding.

Robust Construction for Long-Term Durability

Manufactured from cast iron, mild steel, and alloy steel, the sturdy design ensures stability in challenging workshop environments. The rectangular base paired with a cylindrical head contributes to vibration-free operation and extended machine lifespan.

FAQs of Universal Hydraulic Tool And Cutter Grinder:

Q: How does the Universal Hydraulic Tool And Cutter Grinder ensure high cutting accuracy?

A: This machine features precision slideways and an adjustable grinding head, allowing tools to be ground with an accuracy of 0.02 mm. The controlled hydraulic movement and stable construction further minimize errors during operation.

Q: What tool types are compatible with this grinder?

A: The grinder is suitable for various tools including end mills, reamers, drills, form tools, broaches, and surface and end mill cutters. The blade size and shape depend on the chosen tool attachment for specific operations.

Q: When is it recommended to use the integrated coolant system?

A: The integrated coolant system should be utilized during grinding procedures to prevent overheating, extend grinding wheel life, and ensure consistent finishing, particularly for hard materials up to 60 HRC.

Q: Where can exporters, importers, manufacturers, suppliers, and traders source this machine?

A: The Universal Hydraulic Tool And Cutter Grinder is available from manufacturers, suppliers, or traders, and is commonly exported and imported, with Italy being one of the primary markets mentioned.

Q: What is the process for resharpening tools using this grinder?

A: Resharpening involves mounting the tool or cutter on the adjustable head, setting the required angles using the head swivel mechanism, and then proceeding with hydraulic or manual feed grinding while monitoring table traverse and coolant levels.

Q: What are the major benefits of using a hydraulic tool and cutter grinder?

A: Hydraulic operation provides adjustable cutting force, smooth movement, and improved consistency. These features result in higher accuracy, reduced operator fatigue, and greater versatility across a range of grinding tasks.
