WMW Germany Straight Bevel Gear Generator

Name: WMW Germany Straight Bevel Gear Generator
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

WMW Germany Straight Bevel Gear Generator Specification

Output
High precision bevel gears

Dimension (L*W*H)
3600mm x 2200mm x 2100mm

Machine Type
Straight Bevel Gear Generator

Capacity
Up to 800 mm diameter gears

Color
Grey

Voltage
400 V

Used For
Generating straight bevel gears

Weight
Approx. 5000 kg

Power
9 kW

Feature
Precision gear cutting, heavy-duty construction, robust design

Condition
Used

Workpiece Diameter Range
30 mm to 800 mm

Maximum Module
Up to 16 module

Gear Type
Straight bevel

Spindle Speed
25100 rpm

Automation Grade
Semi-automatic

Control Type
Conventional (manual/semiautomatic)

Worktable Diameter
800 mm

Coolant System
Integrated

Max Pitch Cone Distance
Up to 320 mm

Number of Teeth
6 to 120

WMW Germany Straight Bevel Gear Generator Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About WMW Germany Straight Bevel Gear Generator

Make - WMW Modul (Germany)

Model - ZSTTK

Maximum Gear Diameter - 280 mm

Max. Module - 8 Modules

Max. Face Width - 70 mm

Max. Stroke Length - 80 mm

Minimum Gear Diameter - 20 mm

Extreme Ratio - 1 : 7.5

Stroke Rate - 60 strokes/min to 300 strokes/min

- Complete with Lots of Cutters, Mandrels, Change Gears etc.

- Operating Manual of the Machine is available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/Gq4OLm9GPOw

Precision & Versatility for Your Gear Production

The WMW Germany Straight Bevel Gear Generator offers remarkable versatility with its wide workpiece capacity-accommodating diameters up to 800 mm and modules as large as 16. Its robust build and advanced features are tailored to meet the demanding requirements of modern gear manufacturing environments, guaranteeing accuracy and reliability for straight bevel gear production.

User-Friendly Operation with Semi-Automatic Control

Equipped with conventional manual and semiautomatic control, this machine provides flexible operation for skilled machinists. The intuitive interface, combined with semi-automatic features, enhances productivity while retaining the adaptive touch and expertise of manual adjustment for custom gear manufacturing projects.

Engineered for Efficiency and Heavy-Duty Performance

Constructed with a focus on durability and consistent output, the WMW Germany Straight Bevel Gear Generator integrates a powerful drive, stable worktable, and effective coolant system. This design ensures precise gear cutting in high-volume industrial operations, delivering precision and longevity even under continuous use.

FAQ's of WMW Germany Straight Bevel Gear Generator:

Q: How is the WMW Germany Straight Bevel Gear Generator operated?

A: This gear generator features conventional controls, allowing for both manual and semiautomatic operation. Users can manually adjust parameters or utilize the semi-automatic functions for enhanced efficiency and repeatability during gear cutting processes.

Q: What process does this machine use to generate straight bevel gears?

A: The machine employs a precision gear cutting process specifically designed for straight bevel gears. Workpieces are securely mounted on the robust worktable, and the integrated spindle system, operating between 25 and 100 rpm, enables precise and consistent tooth generation according to input specifications.

Q: When should you use this gear generator?

A: This equipment is ideal for scenarios requiring the production of high-precision straight bevel gears in sizes ranging from 30 mm to 800 mm in diameter. Its robust construction and semi-automatic control make it well-suited for medium- to high-volume gear manufacturing operations or custom gear shops.

Q: Where is this machine best installed and utilized?

A: Given its substantial size (3600 x 2200 x 2100 mm) and weight (about 5000 kg), the WMW Gear Generator is best installed in dedicated industrial gear shops, manufacturing plants, or facilities specializing in precision gear production with access to appropriate power supply (400 V).

Q: What are the main benefits of using this straight bevel gear generator?

A: Key benefits include high precision gear production, versatility in handling various gear sizes and modules, and robust construction for heavy-duty performance. The integrated coolant system further ensures optimal cutting conditions, extending tool life and maintaining workpiece quality.

Q: How does the machine ensure gear cutting accuracy and quality?

A: The gear generator's sturdy design-combined with adjustable spindle speeds, precise worktable rotation, and an integrated coolant system-ensures dimensional accuracy, surface finish quality, and consistency across all manufactured gears.

Q: What types of users or industries are suited for this machine?

A: Exporters, importers, manufacturers, suppliers, and traders in the gear industry or any company requiring reliable straight bevel gear production will benefit most. It supports both high-capacity industrial environments and custom gear workshops requiring precision and adaptability.
