American H-10-48 Horizontal Broaching Machine

Send Inquiry

Request To Call Back

American H-10-48 Horizontal Broaching Machine

Name: American H-10-48 Horizontal Broaching Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

American H-10-48 Horizontal Broaching Machine Specification

Noise Level
Low noise operation

Accuracy
High Precision, within 0.02 mm

Control System
Manual/Panel Controlled

Machine Type
Broaching Machine

Drive
Hydraulic

Frequency
50 Hz

Production Capacity
Variable (Dependent on job)

Cooling System
Integrated coolant system

Lubricating System
Automatic lubrication

Motor Power
7.5 HP (standard)

Features
Heavy-duty frame, quick-change broach setup, safety protection

Operating Temperature
5°C to 45°C

Power Rating
5.5 kW

Voltage
415 V

Model No
H-10-48

Frame Type
Rigid Welded Frame

Product Type
Horizontal Broaching Machine

Technology
Mechanical Broaching

Power Source
Electric

Operating Type
Automatic

Power
7.5 HP

Pressure
Max. 10 Ton

Surface Treatment
Painted

Dimension (L*W*H)
3250mm x 1350mm x 1200mm

Weight (kg)
Approx. 4000

Color
Industrial Gray

Usage & Applications
Broaching splines, keyways, and internal shapes

Broach Stroke
48 inches (1220 mm)

Bed Length
3250 mm

Maximum Broach Diameter
100 mm

Service Support
Available onsite and remote

Broach Return Speed
2 m/min

Cycle Time
Optimized for high throughput

Spindle Type
Precision aligned

Main Hydraulic Pump
Heavy duty, high performance

Hydraulic Oil Tank Capacity
110 liters

Electrical Protection
Overload and short circuit

Foundation Requirement
Level concrete floor, min. 150 mm

Safety Standards
ANSI compliant

Vibration Level
Minimized via anti-vibration mounts

Operator Interface
Simple lever and indicator

Max. Broach Pull
10 tons

Broach Holder
Quick-release type

Power Requirements
3 phase

Maintenance
Low, easy access panels

Fixture Table Dimensions
1200 mm x 400 mm

American H-10-48 Horizontal Broaching Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About American H-10-48 Horizontal Broaching Machine

Make - Coventry Gauge & Tool (England)

Model - H-10-48

Tonnage Capacity - 10 Tons

Stroke Length - 1220 mm (48")

Type - Pull Type ; Hydraulic

- made under License of American Broach & Machine Co, USA.

- Total of 119 pcs (485 kg) of different type of Broaches available as spare.

- With lots of accessories like Fixtures, Arbours etc.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/fL7UVLNj8UE

Optimized Performance for Demanding Broaching Tasks

The H-10-48 delivers robust broaching power with a heavy-duty hydraulic drive and high-precision spindle alignment, ensuring accurate machining even for complex internal shapes. Its quick-change broach holder and 2 m/min return speed boost productivity, making it ideal for both small and large production runs.

Engineered for Operator Safety and Ease of Use

This machine prioritizes operator well-being with ANSI-compliant safety features, minimized vibration, overload protection, and clear operator interfaces. Easy-access panels and automatic lubrication further simplify both daily usage and maintenance procedures, reducing operational downtime.

Versatile Applications Across Industries

From broaching splines and keyways to custom internal forms, the H-10-48 is tailored for industrial environments ranging from manufacturing plants to specialized production workshops. Its flexible fixture table and variable capacity accommodate diverse, job-specific demands.

FAQ's of American H-10-48 Horizontal Broaching Machine:

Q: How does the American H-10-48 Horizontal Broaching Machine maintain high precision during operation?

A: This broaching machine uses a precision-aligned spindle, heavy-duty rigid welded frame, and an advanced hydraulic drive system. These features, in conjunction with anti-vibration mounts and high-performance components, ensure accuracy within 0.02 mm throughout the broaching cycle.

Q: What materials and shapes can be broached using this machine?

A: The H-10-48 is capable of broaching a wide range of internal shapes, such as splines, keyways, and other custom profiles. Its robust design and variable production capacity make it suitable for ferrous and non-ferrous materials commonly used in automotive, aerospace, and general manufacturing industries.

Q: When is regular maintenance required for the H-10-48, and how is it performed?

A: Thanks to its low-maintenance design and automatic lubrication system, routine checks are straightforward. Operators should inspect hydraulic fluid levels, coolant, and safety protections at recommended intervals. Easy-access panels facilitate simple and efficient servicing when necessary.

Q: Where should the H-10-48 broaching machine be installed for optimal performance?

A: The machine should be placed on a level concrete floor with a minimum thickness of 150 mm to provide stable, vibration-free support. Proper foundation ensures accuracy, safety, and longevity of the equipment.

Q: What is the process for changing the broach on this machine?

A: The H-10-48 features a quick-release broach holder, allowing operators to efficiently change broaches with minimal downtime. The clear operator interface and indicator system further assist users in confirming proper installation before operation begins.

Q: How does the machine handle safety and operator protection during use?

A: It is built to ANSI safety standards, features electrical overload and short-circuit protection, safety covers, and a simple operator interface with fail-safes. These safeguards minimize risk during setup and operation, promoting a safe working environment.

Q: What are the main benefits of choosing the H-10-48 broaching machine for your facility?

A: The primary advantages include reliable high-throughput performance, excellent machining accuracy, low noise levels, straightforward maintenance, rapid broach changeovers, and broad application versatility-all while adhering to stringent safety standards and offering robust aftermarket support.
