Colchester Mastiff 1400 Heavy Duty Lathe Machine
Colchester Mastiff 1400 Heavy Duty Lathe Machine

Colchester Mastiff 1400 Heavy Duty Lathe Machine

Price 100000 INR/ Piece

MOQ : 1 Piece

Colchester Mastiff 1400 Heavy Duty Lathe Machine Specification

  • Product Type
  • Manual Lathe Machine
  • Material
  • High-grade Cast Iron
  • Cutting Thickness
  • Up to 20 mm
  • Cutting Speed
  • Variable up to 1800 rpm
  • CNC Or Not
  • No (Manual Operation)
  • Automatic Grade
  • Manual
  • Control System
  • Manual
  • Max. Swing Diameter
  • 400 mm
  • Voltage
  • 415 V
  • Weight (kg)
  • 2100 kg
  • Dimension (L*W*H)
  • 2650 mm x 1100 mm x 1450 mm
  • Capacity
  • Heavy Duty Turning
  • Feature
  • Rigid Construction, Precision, High Torque
  • Color
  • Industrial Grey
  • Number of Spindle Speeds
  • 16
  • Thread Cutting
  • Imperial & Metric, 44 Imperial and 39 Metric threads
  • Lead Screw Diameter
  • 32 mm
  • Distance Between Centers
  • 1250 mm
  • Bed Width
  • 355 mm
  • Type of Chuck
  • 3-jaw and 4-jaw chuck compatible
  • Gearbox
  • Hardened and ground gears
  • Tool Post
  • Four-way turret
  • Max. Turning Length
  • 1250 mm
  • Tailstock Quill Travel
  • 152 mm
  • Lubrication
  • Automatic lubrication system
  • Main Motor Power
  • 7.5 HP
  • Coolant System
  • Built-in
  • Spindle Bore
  • 76 mm


Colchester Mastiff 1400 Heavy Duty Lathe Machine Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Main Domestic Market
  • All India


About Colchester Mastiff 1400 Heavy Duty Lathe Machine

Make - Colchester (England)

Model - Mastiff 1400

Center Height - 270 mm

Length of Job - 1000 mm

Max. Diameter of Job over Bed - 540 mm

Max. Diameter of Job over Cross-Slide - 360 mm

Max. Diameter of Job in Gap - 815 mm

Max. Job Length in Gap - 130 mm

Bed Width - 343 mm

3-Jaw Chuck Diameter - 400 mm

4-Jaw Chuck Diameter - 310 mm

Spindle Speeds - 18 rpm to 1400 rpm

Spindle Bore - 90 mm

- Complete with Job Steady, Gap-Bed piece, 4-Jaw chuck.

- Complete with many different jaws and other accessories.

- Machine is in excellent working condition.


Video of The machine -

https://youtu.be/cnAn5zUIDfU



Precision and Power for Heavy-Duty Turning

With a max turning length of 1250 mm and a swing diameter of 400 mm, the Colchester Mastiff 1400 delivers strength and stability for large, demanding tasks. The high-torque 7.5 HP motor and variable speeds accommodate diverse materials and cutting needs, ensuring precision even under rigorous use.


Versatility and User-Friendly Operation

Supporting both 3-jaw and 4-jaw chucks, this manual lathe handles a wide array of shapes and sizes. The four-way turret tool post streamlines tool changes, while automatic lubrication keeps maintenance straightforward. A built-in coolant system extends the lifespan of both the tool and the workpiece, reducing downtime.


Durability and Rigid Construction

Rigid construction is ensured by the use of high-grade cast iron, minimizing vibrations and promoting consistent machining. Hardened and precision-ground gears in the gearbox guarantee long service life and reliable performance. Industrial grey finishing provides both aesthetic appeal and lasting protection.

FAQ's of Colchester Mastiff 1400 Heavy Duty Lathe Machine:


Q: How does the Colchester Mastiff 1400 ensure accurate thread cutting in both imperial and metric units?

A: The Mastiff 1400 comes equipped with gear settings for 44 imperial and 39 metric threads, allowing precise and versatile thread cutting. The hardened, ground gears and accurate lead screw contribute to high accuracy in pitch selection and machining.

Q: What materials and workpiece sizes can be machined on the Mastiff 1400 lathe?

A: Thanks to its 400 mm max swing diameter, 76 mm spindle bore, and 1250 mm distance between centers, the Mastiff 1400 can handle hefty, large-diameter components made from various metals. The machine's sturdy structure and variable cutting speed support heavy-duty turning on diverse materials.

Q: When is the built-in automatic lubrication system active during machine operation?

A: The automatic lubrication system operates whenever the machine is in use, continually providing essential lubrication to vital components. This reduces wear, maintains smooth operation, and extends the machine's operational life.

Q: Where is the Colchester Mastiff 1400 manufactured and distributed?

A: This lathe is manufactured in the United Kingdom and is available globally through exporters, importers, suppliers, and traders. It is a preferred choice for industries, workshops, and training centres requiring reliable heavy-duty machining capabilities.

Q: What is the process for switching between 3-jaw and 4-jaw chucks?

A: Switching between 3-jaw and 4-jaw chucks involves removing the installed chuck and mounting the desired alternative onto the spindle nose. Both are fully compatible with the Mastiff 1400, providing flexibility for different workholding requirements.

Q: How does using the four-way turret tool post benefit machining operations?

A: The four-way turret tool post enables quick tool changes, reducing setup time and facilitating multi-step operations without manual repositioning. This increases productivity and helps maintain machining accuracy.

Q: What maintenance does the Mastiff 1400 require, and how does the automatic lubrication help?

A: Routine checks for alignment and wear are recommended, but the automatic lubrication system ensures key moving parts are constantly oiled, minimizing manual intervention. This feature results in lower maintenance needs and enhances the machine's longevity.
