Colombo Extra Heavy Duty Lathe Machine

Price 1100 USD ($)/ Piece

Get a Price/Quote

MOQ : 1 Piece

Colombo Extra Heavy Duty Lathe Machine Specification

Product Type
Extra Heavy Duty Lathe Machine

Material
Cast Iron

Cutting Thickness
Up to 10 mm

Cutting Speed
35-1120 RPM

CNC Or Not
No, Manual Lathe

Automatic Grade
Manual

Control System
Manual

Max. Swing Diameter
800 mm

Voltage
415 V

Weight (kg)
4500 kg

Dimension (L*W*H)
4000 x 1300 x 1800 mm

Capacity
High Production

Feature
Robust Build, Vibration Free Operation, Precision Ground Bed

Color
Blue & White

Bed Type
Double V type, flame hardened and ground

Power Supply
Three phase, 415V, 50Hz

Tool Post
Four-way heavy duty

Cross Slide Travel
500 mm

Tailstock Quill Diameter
90 mm

Surface Finish
Precision ground surfaces

Spindle Nose
Standard L0 Type

Chuck Size
400 mm

Spindle Bore
105 mm

Main Motor Power
7.5 HP

Coolant System
Provided

Lead Screw Pitch
6 TPI

Distance Between Centers
3000 mm

Tailstock Travel
220 mm

Carriage Travel
3000 mm

About Colombo Extra Heavy Duty Lathe Machine

Make - Colombo (Italy)

Model - TSF-1600

Center Height - 850 mm

Max. Length of Job - 3000 mm

Max. Diameter of Job over Bed - 1700 mm

Max. Diameter of Job over Cross-Slide - 1200 mm

Bed Width - 1000 mm

Chuck Diameter - 1200 mm

Spindle Speeds - 4 rpm to 290 rpm

Spindle Bore - 120 mm

Weight of Machine - 15.5 tons (approximately)

- With Motorized Rapid Travels of Carriage & Tool-Slide.

- Tool-Slide (Top Slide) also has powered Feed Travels.

- Complete with a very big sized 3-point steady.

- Complete with an extra tool-post for turning purposes.

- Machine recently overhauled in Europe; in excellent working condition.

Video Link - https://youtu.be/ohmg6LGt8vw

Precision and Durability

The double V-type, flame-hardened, and precision-ground bed ensures optimal alignment and minimal wear, providing lasting accuracy for high-volume industrial machining. Its robust cast iron build absorbs vibrations, delivering superior surface finishes and extending machine life.

Versatile High-Capacity Operations

With a 3,000 mm distance between centers and a 105 mm spindle bore, this lathe easily manages heavy and oversized workpieces. Its high production capacity, four-way tool post, and 7.5 HP motor make it ideal for demanding manufacturing and repair environments.

Designed for Efficiency and Safety

The Colombo lathe is equipped with a reliable coolant system and safety-focused manual controls. Its vibration-free performance, ergonomic layout, and precision ground surfaces contribute to operator comfort, consistent output, and reduced work fatigue.

FAQs of Colombo Extra Heavy Duty Lathe Machine:

Q: How does the double V-type, flame-hardened bed benefit the lathe machines performance?

A: The double V-type, flame-hardened bed provides enhanced rigidity and precision, ensuring accurate alignment during heavy-duty operations. The hardening process reduces wear over time, and the ground surface delivers exceptional smoothness, resulting in precise machining and longevity of the machine.

Q: What types of workpieces can the Colombo Extra Heavy Duty Lathe accommodate?

A: This lathe is designed for large and heavy workpieces, thanks to its 3,000 mm distance between centers, 800 mm maximum swing diameter, and 105 mm spindle bore. Its suitable for manufacturing shafts, rolls, and other oversized components used in industrial and engineering sectors.

Q: When should the coolant system be used during machining?

A: The coolant system should be activated whenever performing cutting operations on hard or heat-sensitive materials or conducting prolonged machining sessions. It helps reduce tool wear, improves surface finish, and prevents workpiece deformation caused by excessive heat.

Q: Where can the Colombo lathe be installed for optimal performance?

A: This machine is best suited for installation in dedicated industrial workshops or manufacturing floors with sufficient space and proper three-phase, 415V, 50Hz power supply. Ensure the floor is level and structurally strong to support its 4,500 kg weight and operation.

Q: What is the purpose of the four-way heavy duty tool post?

A: The four-way heavy duty tool post enables quick and secure changing of various cutting tools, increasing efficiency during complex or multi-stage machining processes. Its robust design ensures consistent tool alignment, contributing to high-precision output.

Q: How does manual control enhance the user experience on this lathe?

A: Manual control offers the operator greater flexibility to adjust feed rates, handle delicate machining, and respond instantly to any operational variances. This level of direct interaction is valued in specialized applications where precise, hands-on manipulation is required.

Q: What are the main benefits of choosing this lathe for production environments?

A: Key advantages include its heavy-duty and vibration-free construction for superior surface finishes, high production capacity, easy operation, and durability. Precision-ground surfaces and a reliable coolant system further ensure high efficiency and consistent quality over extended use.
