Fellows Herbert Gear Shaper Machine

Name: Fellows Herbert Gear Shaper Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Fellows Herbert Gear Shaper Machine Specification

Machine Type
Gear Shaper Machine

Capacity
Gear Diameter up to 400 mm

Weight
Approx. 3 to 5 Tons

Color
Green

Power
Main Motor: 5 HP

Voltage
415V, 3 Phase

Feature
High Performance, Durable Construction, Vertical Gear Cutting Capability

Used For
Gear Shaping, Precision Gear Cutting

Condition
Used / Second Hand

Output
Precise External & Internal Gear Cutting

Dimension (L*W*H)
Approx. 2800 x 1400 x 2000 mm

Noise Level
Below 80 dB

Precision Level
±0.02 mm

Feed Rate
Adjustable

Control Type
Manual with Mechanical Operations

Max Gear Width
80 mm

Module Range
Up to 6 Module

Number of Strokes per Minute
Adjustable (Approx. 60-300 SPM)

Cutter Diameter
Up to 127 mm

Drive Type
Gear Driven with Belt Assistance

Table Travel
Longitudinal & Cross Travel Provided

Installation Area Required
Approx. 15 sq. ft.

Stroke Length
160 mm

Coolant System
Integrated

Table Diameter
400 mm

Lubrication System
Centralized Manual Lubrication

Spindle Speed
Variable, 37-150 RPM

Fellows Herbert Gear Shaper Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Fellows Herbert Gear Shaper Machine

Make - Fellows-Herbert (England / USA)

Max. Module Capacity - 4 Modules

Max. Gear Diameter - 250 mm

Max. Stroke Length - 60 mm

Spindle Diameter - 69.5 mm

Stroke Rate - 156 strokes/min to 515 strokes/min

Height between Table to Spindle Body - 150 mm

- Complete with Change Gears.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/hzUAP6liGfk

Exceptional Gear Shaping Precision

Achieve precise gear shaping with the Fellows Herbert Gear Shaper Machine, which boasts a precision level of 0.02 mm. Its robust design ensures consistent accuracy for both external and internal gear cutting, making it ideal for industries where reliable gear production is critical. The machine's variable speed settings and adjustable feed offer superior control, ensuring optimal results for every shaping job.

Comprehensive Mechanical Control

This gear shaper is operated manually with mechanical controls, giving experienced operators full command over the shaping process. Adjustable table travel-both longitudinal and cross-together with a modular cutter capability (up to 6 module), supports a wide variety of gear sizes and types. The central lubrication and integrated coolant system contribute to smooth operation and extended machine life.

Built for Versatility and Longevity

The machine accommodates gear widths up to 80 mm, cutter diameters up to 127 mm, and offers a stroke rate of 60-300 strokes per minute. Constructed for high performance and durability, the Fellows Herbert Gear Shaper Machine meets the demanding needs of manufacturers, exporters, importers, and suppliers in the United Kingdom and beyond. Its sturdy, green build and efficient 5 HP main motor ensure dependable operation.

FAQ's of Fellows Herbert Gear Shaper Machine:

Q: How does the Fellows Herbert Gear Shaper Machine achieve high-precision gear cutting?

A: The machine features a precision level of 0.02 mm, adjustable spindle speeds (37-150 RPM), and a rigid structure. Together, these factors enable consistent and accurate external and internal gear shaping, suitable for demanding industrial applications.

Q: What range of gear sizes can this machine handle?

A: The machine accommodates gear diameters up to 400 mm, gear widths up to 80 mm, and cutter diameters up to 127 mm. It also supports modules up to 6, making it versatile for various gear shaping tasks.

Q: When is manual control beneficial for gear cutting operations?

A: Manual mechanical operations allow skilled operators to finely adjust settings, such as feed rate, stroke rate (60-300 SPM), and table travel. This level of control is crucial for custom or intricate gear shaping jobs requiring tailored adjustments.

Q: Where is this machine commonly used?

A: This gear shaper is suitable for manufacturing facilities, gear repair workshops, and heavy engineering industries. Its capabilities make it popular with exporters, importers, manufacturers, and suppliers, especially in markets like the United Kingdom.

Q: What is the process for maintaining this gear shaper machine?

A: Routine maintenance involves using the centralized manual lubrication system to keep components moving smoothly, checking the integrated coolant system, and conducting regular inspections during non-operation hours to ensure longevity and optimal function.

Q: How does the adjustable table travel enhance machine usage?

A: Longitudinal and cross table travel allow for flexible positioning of workpieces, accommodating different gear sizes and complex shaping needs. This adaptability enhances the range of gear profiles the machine can produce.

Q: What are the key benefits of using this used Fellows Herbert Gear Shaper Machine?

A: Benefits include high shaping accuracy, robust durability, adjustable operational parameters, integrated lubrication and coolant systems, low noise output (below 80 dB), and cost-effectiveness compared to new equipment.
