G Vernier FV250 Universal Milling Machine

Price 200000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

G Vernier FV250 Universal Milling Machine Specification

Rotation
Horizontal & Vertical spindle rotation

Model
FV250

Product Type
Universal Milling Machine

General Use
Metal milling, surface machining, slot and gear cutting

Material
Cast Iron Body, Steel Components

Type
Horizontal & Vertical Universal

Capacity
250 mm (maximum milling width)

Weight (kg)
Approx. 1450 kg

Computerized
No

Automatic
No, Manual

CNC Or Not
Not CNC (Conventional) Machine

Control System
Manual

Table Size
1250 mm x 250 mm

Table Slide Way
Precision ground box type

Floor Space
1850 mm x 1700 mm

Spindle Speed
40 2000 rpm (16 steps)

Power
2.2 kW (3 HP)

Voltage
415 V, 3 Phase, 50 Hz

Dimension (L*W*H)
1850 x 1700 x 1650 mm

Feature
Universal swiveling table, horizontal/vertical spindle, overarm support

Color
Industrial Green

Max. Distance Spindle to Table
400 mm

Table Load Capacity
250 kg

Spindle Taper
ISO 40 (Horizontal & Vertical)

Rapid Feed
1200 mm/min

Table Vertical Travel
400 mm

Lubrication System
Centralized automatic lubrication

T-Slots (number x width x distance)
3 x 16 mm x 63 mm

Noise Level
Less than 75 dB

Table Cross Travel
250 mm

Table Longitudinal Travel
750 mm

Feed Range (Longitudinal, Cross, Vertical)
22 560 mm/min

Main Motor
3 HP / 2.2 kW

Overarm Diameter
105 mm

Coolant Pump
0.09 kW

Arbor Diameter
25.4 mm

G Vernier FV250 Universal Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About G Vernier FV250 Universal Milling Machine

Make - G. Vernier (France)

Model - FV250

Table Size - 1000 mm x 260 mm

XYZ Travel - 710 mm x 260 mm x 475 mm

Spindle Speeds - 28 rpm to 1250 rpm

Spindle Taper - ISO 40

Table Feed Rates - 14 mm/min to 710 mm/min

- Equipped with 3-Axis DRO.

- Equipped with Foot Operated Brake.

- Double Swivel type Vertical Milling Head.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/zTsm7DcPJP4

Precision Engineering for Diverse Milling Needs

The FV250 excels in versatility, accommodating horizontal and vertical milling tasks with ease. Its universal swiveling table and robust overarm support enhance operational flexibility, while the precision-ground box type slideways ensure high accuracy during machining. Built to handle up to 250 kg table loads, it is ideal for various applications from intricate metal surface finishing to gear cutting.

Reliable and User-Friendly Operation

This conventional manual milling machine offers straightforward controls for users, empowered by a smooth central automatic lubrication system and a quiet operation below 75 dB. With feed ranges from 22 to 560 mm/min, rapid feed at 1200 mm/min, and a 16-step spindle speed from 40 to 2000 rpm, operators can easily adapt settings for specific job requirements while maintaining consistent quality.

Durable Construction and Proven Performance

Constructed with a cast iron body and precision steel components, the FV250 is designed for longevity in demanding workshop environments. Its main spindle and overarm dimensions add stability, while the tables capacity allows for larger workpieces. Efficient cooling and centralized lubrication further guarantee extended machine life and reliable performance.

FAQs of G Vernier FV250 Universal Milling Machine:

Q: How does the G Vernier FV250 Universal Milling Machine enhance precision in metalworking?

A: The FV250 uses precision-ground box-type slideways for its table, combined with a rigid cast iron body and stable overarm support. This design minimizes vibration and ensures accurate movement, resulting in precise milling, slotting, and gear cutting operations.

Q: What materials can be processed using the FV250 milling machine?

A: The machine is built primarily for metalworking, handling a variety of metals such as steel, aluminum, and cast iron. Its robust construction and powerful 3 HP motor facilitate efficient and accurate machining of these materials.

Q: When is it recommended to use the horizontal versus the vertical spindle options?

A: The horizontal spindle is ideal for tasks like slotting and surface machining, where horizontal cutting is required, while the vertical spindle is best used for tasks such as face milling, drilling, or when working with workpieces that need vertical engagement.

Q: Where should the FV250 machine be installed for optimal performance?

A: The machine should be installed on a stable, leveled floor, preferably in a workshop or manufacturing environment with adequate space (at least 1850 mm x 1700 mm) to accommodate its dimensions and facilitate easy operation and maintenance access.

Q: How is lubrication managed in the FV250 Universal Milling Machine?

A: This machine features a centralized automatic lubrication system, ensuring continuous and even distribution of lubricant to all critical moving parts. This helps reduce friction, wear, and maintenance needs, ultimately extending the machines lifespan.

Q: What are the main benefits of using a manual, non-CNC universal milling machine like the FV250?

A: The FV250 offers excellent operator control for intricate or small-batch tasks without requiring CNC programming. Its universal table and dual spindle capability mean more versatility for varying operations, while its manual controls provide tactility and flexibility for skilled machinists.

Q: What are the typical processes and applications for the FV250 in an industrial setting?

A: It is widely used for general metal milling, surface finishing, slot cutting, and gear manufacturing. Its robust build and flexible spindle orientation make it suitable for tool rooms, repair shops, and small to medium manufacturing plants.
