Grazioli Ludor 2 Universal Milling Machine

Name: Grazioli Ludor 2 Universal Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Grazioli Ludor 2 Universal Milling Machine Specification

Model
Ludor 2

Rotation
Both clockwise and counterclockwise

Product Type
Universal Milling Machine

General Use
Metalworks, precision engineering, toolroom and production milling operations

Material
Cast Iron Body, Steel Working Parts

Type
Universal

Capacity
Milling up to 450 kg workpiece

Weight (kg)
Approx. 1550 kg

Computerized
No

Automatic
No, Manual feed

CNC Or Not
No

Control System
Manual mechanical

Table Size
1250 mm x 250 mm

Table Slide Way
Dove-tail/Box type

Floor Space
1850 mm x 1700 mm

Spindle Speed
45-2000 rpm (variable, 12 steps)

Power
3 HP main motor

Voltage
415V, 3 Phase, 50Hz

Dimension (L*W*H)
2000 mm x 1700 mm x 1750 mm

Feature
Horizontal & Vertical Spindle, Swivel Table, High-precision Feed, Rigid Construction

Color
Machine Green/Blue (Standard Factory Finish)

Number of T-Slots
3

Cross Table Travel
255 mm

Table Feed
Manual and power feed

Overarm Diameter
105 mm

Longitudinal Table Travel
900 mm

Milling Arbor Diameter
25.4 mm (1 inch)

T-Slot Size
16 mm

Spindle Taper
ISO 40

Vertical Travel
385 mm

Max Distance Spindle to Table
440 mm

Swivel Table Angle
+/- 45 Degrees

Coolant Pump
Included

Main Motor Type
TEFC (Totally Enclosed Fan Cooled)

Grazioli Ludor 2 Universal Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Grazioli Ludor 2 Universal Milling Machine

Make - Grazioli (Italy)

Model - Ludor 2

Table Size - 1400 mm x 325 mm

XYZ Travel - 800 mm x 205 mm x 450 mm

Spindle Taper - ISO 50

Spindle Speeds - 25 rpm to 1350 rpm

Table Feed Rate - 8.5 mm//min to 1120 mm/min

- Equipped with Bracket & Arbour for Horizontal Milling Operations.

- Complete with its Vertical Milling Head.

- With Universal Type Rotating Table.

- Complete with Tool Holders etc.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/y5VTOyfRYs0

Versatile Milling Performance

The Ludor 2's horizontal and vertical spindle design, along with a spacious table and multiple feed options, provides exceptional versatility for a range of milling tasks. With its 45 swivel table and robust 450 kg capacity, users can execute complex setups and achieve accurate results in various production environments.

Sturdy Construction and Reliable Power

Designed with a durable cast iron body and precision-ground steel components, the Ludor 2 ensures stability and minimal vibration during operation. The powerful 3 HP TEFC motor supports sustained performance, while the 415V, 3-phase configuration guarantees consistent output for industrial applications.

Precision Engineering and Safety

The dovetail/box-type slideways enhance table movement precision, and the included coolant pump maintains optimal machining conditions. Manual and power feeds offer users the choice of fine control or efficient workflow, ensuring high-quality milled components while maintaining operational safety.

FAQ's of Grazioli Ludor 2 Universal Milling Machine:

Q: How do I operate the table feeds on the Grazioli Ludor 2 Milling Machine?

A: Operation of the table feed can be performed manually via the handwheels or automatically using the power feed feature. The machine provides both options, allowing for smooth longitudinal and cross travel, which is especially useful for maintaining consistent feed rates during precision milling tasks.

Q: What materials can the Grazioli Ludor 2 handle, and what is its maximum workpiece capacity?

A: The Grazioli Ludor 2 is suitable for machining metal components and precision engineering work. Thanks to its robust construction, dovetail/box-type slideways, and a table supporting up to 450 kg, it can handle a wide range of metals with high stability and accuracy.

Q: When should I use the horizontal versus vertical spindle on this milling machine?

A: The horizontal spindle is ideal for slotting, grooving, and face milling, whereas the vertical spindle is preferred for drilling, end milling, and surface contouring. Users can easily switch between spindle orientations depending on the job requirements and desired milling operations.

Q: Where is the Grazioli Ludor 2 most suitably installed?

A: This machine is best suited for toolrooms, metalworking shops, precision engineering facilities, and manufacturing plants. Due to its size, floor space requirement (1850 x 1700 mm), and weight (approx. 1550 kg), a well-prepared, sturdy industrial floor area is recommended for installation.

Q: What are the benefits of the manual mechanical control system in the Ludor 2?

A: The purely manual control system provides the operator with direct control over all milling processes, enabling high-precision adjustments and flexibility during custom or low-volume production runs. It also minimizes complexity and the need for computerized programming, making it reliable and straightforward for skilled machinists.

Q: How does the included coolant pump enhance the milling process?

A: The integrated coolant pump helps maintain optimal temperature and lubrication at the cutting interface, which reduces tool wear and thermally induced dimensional inaccuracies, resulting in better surface finish and prolonged tool life.

Q: What safety precautions should be observed when using this universal milling machine?

A: Operators should always wear appropriate personal protective equipment (PPE), ensure that all guards and covers are securely in place, use proper clamping techniques for workpieces, and follow the manufacturer's guidelines on speed, feed, and tool selection. Regular maintenance of the TEFC main motor and mechanical components is also essential for safe and efficient operation.
