H. Tschudin HTG-300 Cylindrical Grinder with Relief Grinding Feature

Name: H. Tschudin HTG-300 Cylindrical Grinder with Relief Grinding Feature
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

H. Tschudin HTG-300 Cylindrical Grinder with Relief Grinding Feature Specification

Product Type
Cylindrical Grinder

General Use
Precision cylindrical and relief grinding operations

Material
Cast Iron / Steel Construction

Type
HTG-300

Capacity
Up to 300 mm length

Weight (kg)
1700 kg (Approx.)

Computerized
No

Automatic
Semi-Automatic

Control System
Manual & Hydraulic Controls

Drive Type
Belt Drive

Grinding Diameter
Up to 200 mm

Grinding Length
300 mm

Spindle Speed
Up to 2200 RPM

Grinding Wheel Size
350 mm x 50 mm x 127 mm

Voltage
415 V, 3 Phase

Dimension (L*W*H)
1650 mm x 1300 mm x 1600 mm

Feature
Relief Grinding, High Precision, Compact Design

Color
Machine Tool Grey

Coolant System
Integrated

Model
HTG-300

Work Head Speed
Variable, typically 25300 RPM

Max Workpiece Weight
Up to 50 kg

Lubrication System
Centralized Automatic

Tailstock
Live/Dead Center with Micrometer Adjustment

Relief Grinding Feature
Yes, integrated with main spindle

Power Consumption
Approx. 4 kW

Table Swivel Range
+/- 7

Wheelhead Movement
Manual/Hydraulic

H. Tschudin HTG-300 Cylindrical Grinder with Relief Grinding Feature Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

H. Tschudin HTG-300 Cylindrical Grinder with Relief Grinding Feature About

Make - H. Tschudin (Switzerland)

Model - HTG 300

Center Height - 56 mm

Max. Job Diameter - 105 mm

Max. Length of Job - 300 mm

Grinding Wheel Size - Diameter 300 mm x 40 mm Width

No. of Flutes for Relief Grinding - 2 to 6

- Equipped with a special Relief Grinding Attachment.

- Can work as a normal Cylindrical Grinder as well.

- Features like Auto-Cut, Auto-Compensation, Plunge Grinding, Delay etc.

- Equipped with a Top Mounted Wheel Dresser.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/SiiVUPjU_T4

Relief Grinding Feature

The HTG-300 stands out for its integrated relief grinding system, allowing intricate grinding profiles directly with the main spindle. This feature enhances the machine's versatility, making it ideal for manufacturers seeking precision relief grinding, such as toolmakers and component producers, without requiring extra attachments or secondary operations.

Precision & Efficiency

Designed for high accuracy, the HTG-300 offers a table swivel range of 7, variable work head speeds, and advanced spindle dynamics up to 2200 RPM. Paired with its centralized automatic lubrication and robust belt drive, this ensures uniform grinding results and reduces maintenance, promoting continuous production efficiency.

FAQ's of H. Tschudin HTG-300 Cylindrical Grinder with Relief Grinding Feature:

Q: How does the integrated relief grinding feature benefit precision grinding operations?

A: The integrated relief grinding feature on the HTG-300 enables complex profiles and reliefs to be ground directly, increasing operational accuracy and reducing setup times. This capability is especially advantageous for producing precision-engineered parts with specialized contours.

Q: What types of materials can the HTG-300 handle for grinding operations?

A: Constructed from durable cast iron and steel, the HTG-300 is suitable for grinding a wide range of materials including hardened steel, alloy steel, and cast iron, meeting the demands of both toolmaking and general engineering industries.

Q: When is manual versus hydraulic wheelhead movement recommended on this grinder?

A: Manual wheelhead movement is ideal for delicate adjustments or prototype work, while hydraulic movement ensures consistent, rapid operation during series production or when handling larger batches, offering flexibility for various manufacturing needs.

Q: Where can the HTG-300 be utilized most effectively?

A: The HTG-300's compact design and high precision features make it ideally suited for tool rooms, production workshops, and specialized grinding facilities requiring reliable performance for cylindrical and relief grinding applications.

Q: What is the process for adjusting workpiece alignment and precision on this machine?

A: The HTG-300 features a micrometer-adjusted tailstock and a variable-speed work head for precise workpiece centering and rotation. Combined with its table swivel capability, users can achieve accurate alignment and fine-tune grinding angles for superior finish quality.

Q: How does the automatic lubrication and coolant system support prolonged machine operation?

A: The centralized automatic lubrication system ensures consistent lubrication of critical moving parts, reducing wear and maintenance intervals. Integrated coolant management maintains optimal temperatures during grinding, thus enhancing tool life and workpiece quality.
