Meca Spain Automatic Indexing Turret Drilling Machine
Meca Spain Automatic Indexing Turret Drilling Machine

Meca Spain Automatic Indexing Turret Drilling Machine

Price 100000 INR/ Piece

MOQ : 1 Piece

Meca Spain Automatic Indexing Turret Drilling Machine Specification

  • Motor Power
  • 3 HP
  • Features
  • Automatic indexing multi-spindle turret, heavy-duty rigid frame, precision drilling
  • Noise Level
  • Low (<75 dB)
  • Dimension (L*W*H)
  • 1850 x 1050 x 1800 mm
  • Table Size
  • 650 mm x 420 mm
  • Spindle Speed
  • 65 to 1200 rpm (Variable)
  • Frequency
  • 50 Hz
  • Cutting Area
  • Multiple turret positions, up to 420 mm traverse
  • Diameter
  • Drilling up to 20 mm
  • Condition
  • Used / Good Working Condition
  • Machine Type
  • Indexing Turret Drilling
  • Product Type
  • Automatic Indexing Turret Drilling Machine
  • Material
  • Heavy Duty Cast Iron, Steel Components
  • Computerized
  • No
  • Automatic Grade
  • Automatic
  • CNC Or Not
  • Not CNC
  • Control System
  • Electromechanical Relay Control
  • Voltage
  • 415V (Three Phase)
  • Power
  • 3 kW (Approx)
  • Power Source
  • Electric
  • Weight (kg)
  • Approx 1200 kg
  • Capacity
  • Multi-Spindle, Suitable up to 20 mm Diameter Drilling
  • Color
  • Industrial Green & Grey
  • Usage & Applications
  • For batch and mass production drilling operations, metal and non-metal workpieces
  • Electrical Protection
  • Overload and Phase Failure Protection
  • Tool Change
  • Manual and Quick Indexing
  • Main Shaft Bearing Type
  • Precision Tapered Roller Bearings
  • Maximum Workpiece Height
  • 400 mm
  • Clamping Type
  • Hydraulic / Mechanical
  • Surface Finish Accuracy
  • IT7 Tolerance
  • Drilling Head Travel
  • Up to 150 mm
  • Chuck Size
  • Up to 20 mm
  • Coolant System
  • Integrated Recirculating System
  • Turret Indexing Mechanism
  • Automatic with Positive Locking
  • Feed Type
  • Automatic Feed with Adjustable Rate
  • Number of Turret Stations
  • 6 Positions
  • Work Table Movement
  • Manually Adjustable X and Y Axis
  • Safety Features
  • Emergency Stop, Interlock Guards
  • Lubrication
  • Centralized Automatic System
  • Installation Area Required
  • 2.5 x 2.0 meters


Meca Spain Automatic Indexing Turret Drilling Machine Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Main Domestic Market
  • All India


About Meca Spain Automatic Indexing Turret Drilling Machine

Make - Meca (Spain)

Model - TR-1

Drilling Capacity - 16 mm

Max. Feed Length - 150 mm

Spindle Speed Range - 275 rpm to 4,010 rpm

Clamping Table Size - 350 mm x 300 mm

Base Plate Size - 445 mm x 315 mm

Distance between Spindle Center to Vertical Column - 230 mm

Max. Distance between Spindle Nose to Table Top - 430 mm

- Automatic Indexing 6-Station Turret Head.

- Complete with Coolant Pump and Tank.

- Machine is in excellent working condition.


Video of The Machine -

https://youtu.be/WIy24NtcNuo



Enhanced Productivity with Automatic Indexing

The six-position turret with automatic indexing and positive locking allows users to swiftly switch between drilling tools, streamlining repetitive drilling operations for batch and mass production jobs. This automation reduces setup times, increases throughput, and enhances overall production efficiency.


Precision and Durability You Can Rely On

Constructed from heavy-duty cast iron and steel components, the machine features precision-tapered roller bearings and an IT7 surface finish accuracy. These elements ensure consistent drilling precision and prolong machine life, even under intensive operation in demanding factory settings.


Integrated Systems for Optimal Operation

The centralized automatic lubrication and integrated recirculating coolant systems keep vital components well-maintained, contributing to smooth movements, reduced wear, and stable operation. With both hydraulic and mechanical clamping, as well as reliable safety interlocks, the operator's security and the workpiece's integrity are assured.

FAQ's of Meca Spain Automatic Indexing Turret Drilling Machine:


Q: How does the automatic turret indexing mechanism work on this drilling machine?

A: The machine features an automatic indexing turret with six pre-set positions, allowing quick and secure rotation between tools. The positive locking mechanism ensures precise alignment of each station during drilling, enabling seamless and accurate tool changes without manual repositioning.

Q: What is the maximum drilling capacity and workpiece height supported by the Meca Spain Turret Drilling Machine?

A: This turret drilling machine can accommodate drilling diameters of up to 20 mm and supports a maximum workpiece height of 400 mm, making it suitable for a wide variety of batch and mass production applications.

Q: When should the integrated coolant and lubrication systems be used?

A: Both the recirculating coolant system and centralized automatic lubrication should be kept operational during all drilling processes. These systems are designed to maintain optimal temperatures, minimize wear on moving parts, and ensure sustained precision and efficiency.

Q: Where is this machine ideally used and installed?

A: The Meca Spain Turret Drilling Machine is ideal for installation in industrial manufacturing environments such as metalworking plants, fabrication shops, or workshops engaged in repetitive, precision drilling. It requires a 2.5 x 2.0 meter area for proper setup and operation.

Q: What is the process for changing drilling tools on this machine?

A: Tool changes are performed manually using the quick-indexing turret feature. The operator simply releases the current tool, rotates the turret to the desired station, and locks it in place, readying the new tool for the next drilling cycle with minimal downtime.

Q: What safety features are included to protect operators during machine usage?

A: Safety is ensured through emergency stop buttons, interlock guards, electrical overload and phase failure protection, as well as low operational noise. These features collectively minimize risk and promote a safer work environment.

Q: What are the main benefits of using this machine for production drilling?

A: Users benefit from rapid multi-tool changes, high surface finish accuracy (IT7), automated feed rates, and robust durability. The system's automation and integrated maintenance minimize downtime and maximize productivity, making it an advantageous choice for repetitive, high-precision drilling tasks.
