MSZ Hungary EE-800 Heavy Duty Lathe Machine

Name: MSZ Hungary EE-800 Heavy Duty Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MSZ Hungary EE-800 Heavy Duty Lathe Machine Specification

Product Type
Heavy Duty Lathe Machine

Material
High-grade Cast Iron and Alloy Steel

Cutting Thickness
Up to 80 mm

Cutting Speed
Up to 1200 RPM

CNC Or Not
No

Automatic Grade
Manual

Control System
Manual

Max. Swing Diameter
800 mm

Voltage
415 V, 3 Phase, 50 Hz

Weight (kg)
8000 kg (approx.)

Dimension (L*W*H)
4500 mm x 1700 mm x 1700 mm

Capacity
Heavy-Duty Industrial Machining

Feature
High Rigidity, Precision Ground Bed, Wide Range of Spindle Speeds, Robust Construction

Color
Industrial Green with Red Accents

Feed Range (Longitudinal/Transverse)
0.06 2.5 mm/rev

Main Motor Power
11 kW (15 HP)

Distance Between Centers
3000 mm

Tailstock Quill Diameter
110 mm

Chuck Size
400 mm

Thread Range (Metric)
1 30 mm

Tailstock Quill Travel
250 mm

Thread Range (Inch)
2 56 TPI

Lead Screw Diameter
50 mm

Bed Width
600 mm

Spindle Bore
105 mm

MSZ Hungary EE-800 Heavy Duty Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About MSZ Hungary EE-800 Heavy Duty Lathe Machine

Make - MSZ (Hungary)

Model - EE-800-01

Center Height - 410 mm

Max. Length of Job - 3000 mm

Max. Job Diameter over Bed - 810 mm

Max. Job Diameter over Cross-Slide - 520 mm

Max. Job Diameter in Gap - 1000 mm

Chuck Diameter - 800 mm

Bed Width - 490 mm

Spindle Speeds - 5.6 rpm to 900 rpm

Spindle Bore - 70 mm

Max. Job Length in Gap - 300 mm

- With Motorised Rapid Travel of the Carriage & Cross-Slide.

- Complete with Job Steady, Follow Rest, other accessories etc.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/-RzBhVewX-Y

Superior Build Quality for Industrial Demands

Constructed from high-grade cast iron and alloy steel, the EE-800 lathe offers lasting durability and precision. Its robust 8000 kg frame provides stability during rigorous machining operations, minimizing vibration and ensuring accurate results even in heavy-duty environments.

Precision and Versatility in Machining

This lathe enables versatile machining for both metric and inch threading, with feed ranges adaptable from 0.06 to 2.5 mm/rev. The precision-ground bed and wide spindle speed allow operators to achieve consistent surface finishes and shapes, catering to diverse industrial needs.

Manual Control for Reliable Operations

Featuring a manual control system, the MSZ Hungary EE-800 prioritizes operator oversight and flexibility. This setup is ideal for skilled machinists who require custom adjustments during turning, threading, and facing tasks while maintaining full control over the machining process.

FAQ's of MSZ Hungary EE-800 Heavy Duty Lathe Machine:

Q: How is the MSZ Hungary EE-800 lathe machine operated?

A: The EE-800 lathe is manually controlled, allowing the operator to oversee the entire machining process, make real-time adjustments, and customize operations for a variety of workpieces.

Q: What materials are used in the construction of the EE-800 lathe machine?

A: This machine is constructed from high-grade cast iron and alloy steel, providing high rigidity, robust structure, and long-lasting durability suitable for demanding industrial use.

Q: When is the EE-800 lathe most beneficial in machining processes?

A: The machine is ideal for operations requiring heavy-duty machining, precision turning, threading, and facing of large or tough materials, especially where accuracy and repeatability are essential.

Q: Where can the EE-800 lathe machine be installed?

A: It is suited for industrial workshops, manufacturing plants, and heavy engineering facilities that demand high-capacity lathes for large-scale machining jobs.

Q: What is the process for threading on the EE-800 lathe machine?

A: Threading is performed by selecting suitable thread ranges: 1-30 mm for metric threads and 2-56 TPI for inch threads, utilizing the manual feed system for controlled, accurate thread production.

Q: How does the machine benefit users in industrial settings?

A: Users gain high productivity and precise results due to the machine's wide feed range, substantial spindle bore, robust construction, and capacity to handle thick and heavy workpieces. The manual system also allows skilled adjustments during machining.

Q: What is the maximum workpiece size that the EE-800 lathe can accommodate?

A: The lathe can manage workpieces up to a maximum swing diameter of 800 mm, a bed width of 600 mm, and a distance between centers of 3000 mm, supporting substantial machining requirements.
