Oerlikon Switzerland 1500 mm Length Lathe Machine

Name: Oerlikon Switzerland 1500 mm Length Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Oerlikon Switzerland 1500 mm Length Lathe Machine Specification

Product Type
Conventional Lathe Machine

Material
High-quality cast iron

Cutting Thickness
Up to 50 mm

Cutting Speed
Variable, up to 2500 RPM

CNC Or Not
No

Automatic Grade
Manual

Control System
Manual

Max. Swing Diameter
400 mm

Voltage
415 V AC

Weight (kg)
Approx. 1200 kg

Dimension (L*W*H)
1500 mm x 750 mm x 1200 mm

Capacity
Suitable for medium-duty turning operations

Feature
Swiss precision workmanship, heavy-duty construction

Color
Industrial Gray

Suitable For
Metal and alloy turning operations

Tool Post
Four-way

Phase
Three Phase

Lubrication System
Integrated

Gearbox
Multi-step gear system

Lead Screw Pitch
6 TPI

Chuck Size
250 mm

Spindle Bore
52 mm

Safety Features
Overload protection, emergency stop

Distance Between Centers
1000 mm

Spindle Nose
ISO Standard

Noise Level
< 75 dB

Surface Finish
Ground and hardened

Tailstock Quill Travel
120 mm

Motor Power
3 HP

Coolant System
Fitted

Bed Type
Solid one-piece bed

Oerlikon Switzerland 1500 mm Length Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

Oerlikon Switzerland 1500 mm Length Lathe Machine About

Make - Oerlikon (Switzerland)

Center Height - 200 mm

Max. Length of Job - 1500 mm

Max. Diameter of Job over Bed - 400 mm

Max. Diameter over Cross-Slide - 260 mm

Max. Swing Diameter in Gap - 500 mm

Bed Width - 330 mm

Chuck Diameter - 250 mm

Spindle Bore - 40 mm

- Equipped with Taper Turning Attachment.

- Complete with a 3-Point Steady.

- Machine in excellent working condition.

Video of The Machine -

https://youtu.be/sJc1s3YimJk

Engineered for Precision and Performance

This lathe incorporates Swiss workmanship and a solid one-piece bed, ensuring stability and enhanced accuracy even during demanding operations. The ground and hardened surface finish contributes to minimal wear and consistently high-quality results, supporting both routine and specialized metalworking tasks.

Flexible Turning for Metal and Alloys

With a maximum swing of 400 mm, a distance of 1000 mm between centers, and capability for cutting up to 50 mm thickness, this lathe is ideal for a wide range of turning jobs. Its integrated coolant and lubrication systems facilitate smooth operations, reducing heat and friction for superior part finishes.

User-Friendly and Safe Operation

The lathe features a manual, easy-to-use control system, four-way tool post, and essential safety mechanisms like overload protection and emergency stop. Its ergonomic design reduces operator fatigue, while low noise levels and a fitted coolant system make the workspace safer and more comfortable.

FAQ's of Oerlikon Switzerland 1500 mm Length Lathe Machine:

Q: How is the Oerlikon 1500 mm Lathe Machine suited for metal and alloy turning operations?

A: The lathe is designed with a robust structure, Swiss precision, and variable cutting speed up to 2500 RPM, making it highly effective for turning various metals and alloys. Its multi-step gearbox and integrated lubrication aid in handling medium-duty workpieces with accuracy.

Q: What safety features are integrated into this lathe machine?

A: Key safety features include overload protection and an emergency stop button, which help prevent accidents and machine damage during operation. These features create a safer working environment for operators.

Q: When should the integrated lubrication and coolant systems be used?

A: These systems are intended for use during all turning operations, particularly when working with harder metals or longer runs. They efficiently reduce wear and extend the machine's lifespan by managing heat and friction.

Q: Where can this lathe machine be utilized most effectively?

A: The Oerlikon 1500 mm Lathe Machine is suitable for industrial workshops, manufacturing facilities, and metal fabrication centers that require reliable, precise, and medium-duty turning capabilities.

Q: What is the process for changing cutting speed or spindle speed?

A: Cutting speed can be adjusted using the machine's multi-step gearbox, which allows selection of different speeds up to 2500 RPM. This ensures optimum performance based on the material and cutting requirements.

Q: How does the solid one-piece bed benefit operational accuracy?

A: The solid one-piece bed provides exceptional rigidity and stability, minimizing vibrations. This leads to improved surface finishing and precise machining outcomes, making it ideal for demanding metalworking applications.
