Rigiva Italy Double Spindle Milling Machine

About Rigiva Italy Double Spindle Milling Machine

Make - Rigiva (Italy)

Table Size - 1500 mm x 355 mm

XYZ Travels - 1200 mm x 350 mm x 500 mm

Horizontal Spindle Speeds - 25 rpm to 1200 rpm

Vertical Spindle Speeds - 40 rpm to 1300 rpm

Horizontal Spindle Taper - ISO 50

Vertical Spindle Taper - ISO 50

Table Feed Rates of Travel - 12 mm/min to 640 mm/min

Horizontal Travel of Over-Arm - 760 mm

- Equipped with 3-Axis DRO.

- Over-Arm Travel of Vertical Head Slide for Extra Wide Jobs.

- Suitable for Horizontal, Vertical & Angular Milling Operations.

- Complete with Bracket and Arbour for Horizontal Milling.

- Complete with a very big size Milling Vice, Tool Holders, other accessories.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/SjDHe0ZtaZY
