Sachman Italy 2000 mm X 560 mm Bed Milling Machine
Sachman Italy 2000 mm X 560 mm Bed Milling Machine

Sachman Italy 2000 mm X 560 mm Bed Milling Machine

Price 100000 INR/ Piece

MOQ : 1 Piece

Sachman Italy 2000 mm X 560 mm Bed Milling Machine Specification

  • Model
  • Sachman Italy
  • Rotation
  • Spindle: Both Clockwise & Counter-Clockwise
  • Product Type
  • Bed Milling Machine
  • General Use
  • Heavy-duty metal milling
  • Material
  • Cast Iron Body
  • Type
  • Horizontal Bed Type
  • Capacity
  • Medium to heavy-duty milling
  • Weight (kg)
  • Approx. 4600 kg
  • Computerized
  • No
  • Automatic
  • No (Manual Operation)
  • CNC Or Not
  • Conventional (Not CNC)
  • Control System
  • Manual
  • Table Size
  • 2000 mm x 560 mm
  • Table Slide Way
  • Box type
  • Floor Space
  • Approx. 3600 mm x 3200 mm
  • Spindle Speed
  • 30 1500 RPM
  • Power
  • 7.5 kW
  • Voltage
  • 380 V, 50 Hz
  • Dimension (L*W*H)
  • Approx. 3600 mm x 3200 mm x 2100 mm
  • Feature
  • Long table, heavy-duty construction, precision gears
  • Color
  • Standard Industrial Grey/Blue
  • Minimum Distance Spindle To Table
  • 30 mm
  • Vertical Table Travel
  • 500 mm
  • Working Surface Slots
  • 5 T-slots, each 18 mm wide
  • Longitudinal Table Travel
  • Approx. 1700 mm
  • Maximum Distance Spindle To Table
  • 530 mm
  • Coolant System
  • Provided
  • Lubrication System
  • Automatic centralized lubrication
  • Feed Rate
  • 10 to 520 mm/min
  • Cross Table Travel
  • 560 mm
  • WorkingSpeed
  • Variable
  • Rapid Traverse Rate
  • 1200 mm/min
  • Spindle Taper
  • ISO 50


Sachman Italy 2000 mm X 560 mm Bed Milling Machine Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Main Domestic Market
  • All India


About Sachman Italy 2000 mm X 560 mm Bed Milling Machine

Make - Sachman (Italy)

Table Size - 2000 mm x 560 mm

XYZ Travel - 1800 mm x 800 mm x 750 mm

Spindle Speeds - 30 rpm to 2000 rpm

Spindle Taper - ISO 45

Feed Rates of Travel - 1.5 mm/min to 600 mm/min

Max. Height between Table to Spindle Nose - 800 mm

- Universal Double-Swivel type Head for Vertical, Horizontal & Angular Milling.

- Equipped with a 3-Axis DRO.

- Machine is in excellent working condition.


Video of The machine -

https://youtu.be/3EN5EFnuuUs



Precision and Reliability for Heavy-Duty Applications

The Sachman Italy Bed Milling Machine is designed for industries demanding exactness and durability. With a long worktable and box-type slideways, this machine ensures stable performance during even the most intensive milling tasks. Whether you're involved in manufacturing, engineering, or metal fabrication, it guarantees consistent results, supported by a powerful 7.5 kW motor and robust cast iron construction.


Efficient Manual Operation for Versatile Milling

This conventional (non-CNC) machine offers variable working speeds and a broad range of spindle speeds, allowing operators to adapt to different metal milling requirements. The inclusion of an automatic centralized lubrication system extends component life and reduces maintenance downtime. Its practical features, such as 5 wide T-slots and a comprehensive coolant system, streamline the milling process for enhanced productivity.

FAQ's of Sachman Italy 2000 mm X 560 mm Bed Milling Machine:


Q: How does the Sachman Italy Bed Milling Machine benefit a heavy-duty metalworking operation?

A: With its robust cast iron construction, long table, variable working speeds, and automatic lubrication, the machine is ideal for medium to heavy-duty milling tasks, delivering stability, precision, and reduced operational downtime.

Q: What are the main uses of this bed-type milling machine?

A: This machine is suited for milling, drilling, and boring tasks in engineering, manufacturing, and fabrication industries, particularly where precision and handling of large or heavy workpieces are required.

Q: Where is the Sachman Italy Bed Milling Machine typically installed?

A: It is typically installed in industrial workshops, metalworking factories, and manufacturing units needing a reliable, heavy-duty milling solution with ample floor space.

Q: How is the milling process conducted with this machine?

A: Operation is manual, utilizing variable speed and feed controls to perform precise milling along longitudinal, cross, and vertical axes. The set-up is supported by box-type slideways and an automatic lubrication system for smooth functioning.

Q: When should the machine's lubrication system be checked or maintained?

A: Although the machine features an automatic centralized lubrication system, regular periodic inspections are recommended to ensure consistent lubrication and optimal mechanical performance.

Q: What safety measures should be followed while operating this manual milling machine?

A: Operators should wear appropriate personal protective equipment, ensure the work area is clear, secure all workpieces firmly, and follow standard workshop safety protocols when handling heavy machinery.
