Schlumberger 50 mm Capacity Radial Drilling and Tapping Machine

Send Inquiry

Request To Call Back

Schlumberger 50 mm Capacity Radial Drilling and Tapping Machine

Name: Schlumberger 50 mm Capacity Radial Drilling and Tapping Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Schlumberger 50 mm Capacity Radial Drilling and Tapping Machine Specification

Table Size
600 mm x 450 mm

Frequency
50 Hz

Cutting Area
Up to 50 mm Diameter

Features
Geared Head, Adjustable Arm, Easy Rotation, Robust Construction

Dimension (L*W*H)
1900 mm x 900 mm x 2600 mm

Spindle Speed
702000 RPM (Variable by Pulley)

Motor Power
3 HP

Diameter
Max Drilling Diameter: 50 mm

Machine Type
Radial Arm

Condition
New

Noise Level
Low

Product Type
Radial Drilling and Tapping Machine

Material
Heavy Duty Cast Iron & Alloy Steel

Computerized
No

Automatic Grade
Semi-Automatic

CNC Or Not
Not CNC

Control System
Manual

Voltage
415 V

Power
3.0 HP

Power Source
Electric

Weight (kg)
Approx. 1400 Kg

Capacity
50 mm (Drilling)

Color
Green

Usage & Applications
Drilling, Tapping, Boring in Industrial, Workshop & Manufacturing Plants

Arm Length
1200 mm

Lubrication System
Provision Provided

Floor Space Required
2100 mm x 1200 mm

Column Diameter
220 mm

Coolant Pump
Available (Optional)

Vertical Movement of Arm
750 mm

Number of Speeds
8

Base Plate Material
Cast Iron

Chuck Size
13 mm38 mm

Spindle Travel
250 mm

Swing
1200 mm

Taper in Spindle
MT 5

Height Under Spindle (Max)
1200 mm

Reverse/Forward Tapping
Yes

Max Distance Spindle To Base
1200 mm

Schlumberger 50 mm Capacity Radial Drilling and Tapping Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Schlumberger 50 mm Capacity Radial Drilling and Tapping Machine

Make - Schlumberger (France)

Model - RF 6

Drilling Capacity - 50 mm

Spindle Diameter - 90 mm

Spindle Speeds - 35 rpm to 1800 rpm

Spindle Taper - MT 4

Max. Height between Spindle to Table Top - 920 mm

Min. Distance between Spindle Center to Pillar - 130 mm

Max. Distance between Spindle Center to Pillar - 900 mm

Table Size - 1000 mm x 720 mm

Vertical Clamping Table Size - 800 mm x 800 mm

Spindle Feed Rate - 0.06 mm/min to 0.60 mm/min

Spindle Feed Travel - 350 mm

Head Rotation - 360 degree

Clamping Type - Automatic ; Hydraulic

- With Automatic Tapping Feature.

- Complete with Operating Manual, Quick Change Tool Holder, & Coolant Pump.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/5sfREg7WixY

Precision and Heavy Duty Construction

The machine is expertly built with heavy-duty cast iron and alloy steel, providing exceptional stability and minimal vibration during operation. This robust construction ensures precise results in industrial and workshop settings, even under continuous use. The geared head and adjustable arm facilitate easy rotation and flexibility for drilling varied materials and diameters.

Versatile Operations and Easy Adjustments

Designed for a range of applications, this radial drilling and tapping machine offers smooth vertical and horizontal movement with its 1200 mm arm length and 750 mm vertical travel. Adjustable spindle speed (70-2000 RPM) and a wide chuck size (13 mm to 38 mm) allow for easy adaptation to different project requirements, making it highly suitable for both standard and specialized jobs.

User-Friendly Features and Accessories

This model incorporates thoughtful details such as a manual control system, low noise operation, optional coolant pump, and an efficient lubrication system. Its cast iron base plate and spacious working table (600 mm x 450 mm) enhance stability and workflow efficiency. The machine operates at 415 V with a 3.0 HP motor, requiring minimal floor space for its output capacity.

FAQ's of Schlumberger 50 mm Capacity Radial Drilling and Tapping Machine:

Q: How does the Schlumberger Radial Drilling and Tapping Machine enhance industrial drilling processes?

A: This machine streamlines industrial drilling, tapping, and boring by providing a large drilling capacity (up to 50 mm), a versatile arm for adjustable reach, and variable spindle speeds. Its heavy-duty construction ensures prolonged operation with minimal vibration, while features like the optional coolant pump and lubrication system support efficient, uninterrupted workflows.

Q: What materials and jobs can this machine handle effectively?

A: The machine is built to manage heavy-duty drilling and tapping in materials such as iron, steel, alloys, and castings. It's ideal for use in workshops, manufacturing plants, and industrial environments, handling tasks like precision drilling, threading, and boring of components up to 50 mm diameter.

Q: When should the lubrication and coolant systems be used?

A: The lubrication system should be routinely activated as part of regular maintenance to ensure smooth operation and reduce wear on moving parts. The optional coolant pump is recommended whenever extensive drilling or tapping jobs generate heat, as it helps maintain material integrity and extends tool life.

Q: Where is this machine typically installed?

A: Due to its size and weight (approximately 1400 kg), the machine is best installed on a reinforced shop floor within workshops or manufacturing plants. It requires a floor space of 2100 mm x 1200 mm and access to a 415 V electric power supply.

Q: What are the steps for adjusting spindle speed and arm movement?

A: Spindle speed is adjusted via the pulley system, offering eight variable speeds between 70-2000 RPM. The radial arm's vertical and rotational adjustments are made manually, using the provided controls to set the ideal drilling position based on workpiece size and desired drilling angle.

Q: What are the main benefits of using this machine compared to standard drilling machines?

A: The main advantages include greater drilling capacity, enhanced arm adjustability for hard-to-reach areas, reduced vibration for precision results, and the ability to perform multiple operations (drilling, tapping, boring) on large or heavy workpieces. Its robust build also ensures reliability in high-volume production environments.
