Stanko 2A614 Horizontal Boring Machine

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Stanko 2A614 Horizontal Boring Machine Specification

Frequency
50 Hz

Voltage
380V

Control System
Manual with Electric Panel

Lubricating System
Automatic lubrication

Noise Level
< 80 dB

Production Capacity
High

Cooling System
Centralized Coolant System

Operating Temperature
5C to 40C

Power Rating
7.5 kW

Drive
Gear Driven

Features
Heavy-duty frame, robust spindle, high precision

Machine Type
Horizontal Boring Machine

Model No
2A614

Frame Type
Heavy Cast Iron Construction

Motor Power
7.5 kW

Accuracy
0.02 mm

Product Type
Horizontal Boring Machine

Technology
Conventional

Power Source
Electrical

Operating Type
Semi-Automatic

Power
7.5 kW

Surface Treatment
Painted

Dimension (L*W*H)
3400 x 1400 x 1850 mm

Weight (kg)
6200 kg

Color
Green

Usage & Applications
Precision boring, drilling, milling operations in metalworking

Safety Systems
Emergency Stop Switch

Chuck Type
T-Slot Table

Cross Travel (Z-Axis)
1000 mm

Cooling Liquid Capacity
40 Liters

Machine Finish
Industrial Grade

Vertical Travel (Y-Axis)
950 mm

Maximum Workpiece Diameter
900 mm

Protection Class
IP54

Table Maximum Load
2000 kg

Spindle Travel (W-Axis)
560 mm

Spindle Feed Range
0.04 2 mm/rev

Installed Power
8.0 kW

Longitudinal Table Travel (X-Axis)
1250 mm

Rotary Table
Available, Manual

Boring Depth
Up to 560 mm

Main Motor Type
3 Phase Induction Motor

Tool Holder Type
Morse Taper No. 5

Table Size
1100 x 1000 mm

Machine Condition
Ready to use

Spindle Diameter
80 mm

Stanko 2A614 Horizontal Boring Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Stanko 2A614 Horizontal Boring Machine

Make - Stanko-Import (Russia)

Model - 2A614

Spindle Diameter - 80 mm

Table Size - 1000 mm x 800 mm

Cross Travel - 800 mm

Vertical Travel - 800 mm

Longitudinal Travel - 1000 mm

Spindle Travel - 425 mm

Facing Chuck Diameter - 500 mm

Spindle Taper - MT 5

Spindle Speeds - 20 rpm to 1600 rpm

- Complete with Facing Chuck & Tail-Stock.

- Equipped with DRO.

- Machine is in excellent working condition.

Video of the Machine-

https://youtu.be/tClJ2f91eaA

Precision Metalworking Capabilities

With high-accuracy boring, drilling, and milling, the Stanko 2A614 ensures exceptional results for complex metalworking tasks. The sturdy machine frame and robust spindle support stable, repeatable operations where precision is critical for manufacturing or engineering applications.

Heavy-Duty Performance and Robust Design

Engineered with a heavy cast iron frame and a powerful 7.5 kW gear-driven motor, the 2A614 accommodates heavy workpiecesup to 2000 kg. Its table size (1100 x 1000 mm) and load capacity make it optimal for large, high-production output.

Operator-Centric Features and Safety

The machine incorporates a manual control system with an electric panel, a centralized cooling system, and automatic lubrication for seamless operation. Safety is enhanced with an emergency stop switch and IP54 protection class, providing a secure workspace.

FAQs of Stanko 2A614 Horizontal Boring Machine:

Q: How does the Stanko 2A614 ensure high precision in boring and milling operations?

A: The Stanko 2A614 is designed with a robust spindle and gear-driven mechanism, providing an accuracy of 0.02 mm. Its heavy cast iron frame minimizes vibrations, while features like Morse Taper No. 5 tool holder and a stable table structure ensure consistency and precision in all operations.

Q: What is the process for operating the rotary T-slot table, and what advantages does it offer?

A: The rotary table, operated manually, allows precise indexing and positioning of the workpiece, facilitating multi-sided machining. The T-slot design secures workpieces firmly, improving setup flexibility and enabling complex machining tasks without frequent repositioning.

Q: When is this horizontal boring machine ideal to use in industrial applications?

A: This machine excels when high accuracy and heavy loading are required, making it perfect for large metal components in manufacturing, tool rooms, or maintenance shops. Its high production capacity and load-bearing table support continuous, intensive use.

Q: Where can the Stanko 2A614 be installed, considering power and space requirements?

A: It is suitable for installation in factories or workshops equipped with a 380V, 50 Hz, three-phase power supply. The machines dimensions (3400 x 1400 x 1850 mm) require ample floor space and a stable foundation to ensure optimal performance.

Q: What are the benefits of the centralized coolant and automatic lubrication systems?

A: The centralized coolant system efficiently manages heat during machining, extending tool life and maintaining surface finish quality. Automatic lubrication reduces wear on mechanical components, further enhancing the machines longevity and reducing maintenance intervals.

Q: How is operator safety addressed during the operation of this machine?

A: Safety features include an emergency stop switch, reliable manual controls, and an IP54 protection class that shields electrical components from dust and water. These measures create a safer working environment for operators during extended use.
