TOS FA5V Heavy Duty Pure Vertical Milling Machine

Name: TOS FA5V Heavy Duty Pure Vertical Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS FA5V Heavy Duty Pure Vertical Milling Machine Specification

Model
FA5V

Rotation
Spindle Rotation

Product Type
Pure Vertical Milling Machine

General Use
Heavy duty industrial milling operations

Material
High grade cast iron

Type
Pure Vertical

Capacity
High

Weight (kg)
3200 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
1600 x 400 mm

Table Slide Way
Box type

Floor Space
2400 x 2200 mm

Spindle Speed
35 - 1800 RPM

Power
7.5 kW

Voltage
415 V

Dimension (L*W*H)
2400 x 2200 x 2100 mm

Feature
Heavy duty construction, precision machining

Color
Industrial Green & Grey

Main Motor
7.5 kW / 10 HP

Feed Rate Range
8 400 mm/min

Max. Vertical Travel of Spindle Head
500 mm

Coolant System
Provided

Cross Travel (Table Y-Axis)
400 mm

Longitudinal Travel (Table X-Axis)
1250 mm

Spindle Taper
ISO 50

Number of Feed Rates
18

Lubrication System
Centralized automatic

Distance from Table to Spindle Nose
70 - 570 mm

Maximum Load on Table
700 kg

TOS FA5V Heavy Duty Pure Vertical Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS FA5V Heavy Duty Pure Vertical Milling Machine

Make - TOS (Czech Republic)

Model - FA5V

Table Size - 2000 mm x 425 mm

XYZ Travel - 1400 mm x 450 mm x 450 mm

Spindle Taper - ISO 50

Spindle Speeds - 18 rpm to 1400 rpm

Table Feed Rates - 10 mm/min to 1250 mm/min

Spindle Motor - 11 kW

Head Swivel Angle - +45 degree to -45 degree

Spindle Quill Diameter - 210 mm

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/PLhn1I0APO8

Exceptional Load Capacity and Durability

Built for rigorous industrial environments, the TOS FA5V can withstand loads up to 700 kg and is constructed from high-grade cast iron. Its robust design ensures stability, minimal vibration, and extended operational lifespan even under sustained heavy-duty use.

High Precision Manual Control

Operators benefit from 18 feed rate options (8-400 mm/min), a spindle head travel up to 500 mm, and longitudinal table movement of 1250 mm. The manual control system, with an ISO 50 spindle taper, offers precise adjustments for diverse milling operations without computerized intervention.

Efficient and Safe Operation Systems

A provided coolant system, along with a centralized automatic lubrication system, safeguards the machine components and workpieces during extended runs. The spacious table and box-type slide way further enhance usability and accuracy, supporting high-volume production cycles.

FAQ's of TOS FA5V Heavy Duty Pure Vertical Milling Machine:

Q: How does the centralized automatic lubrication system benefit the TOS FA5V milling machine?

A: The centralized automatic lubrication system ensures that all critical components receive consistent lubrication, reducing wear and minimizing maintenance. This leads to a longer equipment lifespan and smoother, more reliable milling operations.

Q: What materials and workpiece sizes can be handled by the TOS FA5V?

A: The TOS FA5V is capable of handling workpieces up to 700 kg on its 1600 x 400 mm table, making it suitable for large and heavy-duty materials, including steel, cast iron, and other industrial metals.

Q: When should I choose the TOS FA5V over a CNC milling machine?

A: Choose the TOS FA5V when manual control and hands-on adjustments are preferred for complex, custom, or low-volume milling tasks, particularly in environments where operator expertise is vital and automation is not a priority.

Q: Where can the TOS FA5V be installed considering its floor space requirements?

A: The machine requires a floor space of 2400 x 2200 mm with a height of 2100 mm. It is ideal for spacious industrial workshop settings that can accommodate heavy machinery and ensure safe operational distances.

Q: What is the process for changing the feed rate or spindle speed on the FA5V?

A: Feed rates and spindle speeds are adjusted manually via designated levers and selectors. With 18 available feed rates and spindle speeds ranging from 35 to 1800 RPM, operators can easily tailor the machine's operation to their specific material and machining requirements.

Q: How is the TOS FA5V maintained to ensure optimal performance?

A: Routine checks on the lubrication and coolant systems, periodic inspection for wear, and keeping the slide ways clean will uphold precision and reliability. Thanks to its automatic lubrication feature, maintenance intervals are less frequent and more straightforward.

Q: What are the main benefits of using the TOS FA5V for heavy-duty milling operations?

A: The key benefits include high load capacity, accurate manual operation, versatility for a range of industrial materials, durable cast iron construction, and advanced safety and maintenance systems, all contributing to improved productivity and operational reliability.
