TOS SU 50A / 2000 Heavy Duty Lathe Machine

Price 6000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS SU 50A / 2000 Heavy Duty Lathe Machine Specification

Product Type
Heavy Duty Lathe Machine

Material
Cast Iron

Cutting Speed
16 - 2240 RPM

CNC Or Not
No

Automatic Grade
Manual

Control System
Manual

Max. Swing Diameter
500 mm

Voltage
415 V

Weight (kg)
Approximately 3800 kg

Dimension (L*W*H)
3400 x 1300 x 1500 mm

Capacity
2000 mm Between Centers

Feature
Heavy Duty, Precision, Hardened Bed

Color
Green / Blue

Chuck Size
315 mm

Range of Longitudinal Feed
0.05 2.8 mm/rev

Bed Type
Induction Hardened

Spindle Bore
65 mm

Tailstock Quill Travel
200 mm

Range of Cross Feed
0.025 1.4 mm/rev

Centre Height
250 mm

Bed Width
400 mm

Tailstock Quill Diameter
75 mm

Thread Cutting Metric Range
0.5 30 mm

Distance Between Centers
2000 mm

Coolant Pump Motor
0.12 kW

Main Motor Power
7.5 HP

Lead Screw Diameter
35 mm

Thread Cutting Inch Range
2 60 TPI

Number of Spindle Speeds
18

About TOS SU 50A / 2000 Heavy Duty Lathe Machine

Make - TOS-Kurim (Czech Republic)

Model - SU 50A / 2000

Center Height - 255 mm

Max. Length of Job - 2000 mm

Max. Job Diameter over Bed - 500 mm

Max. Job Diameter over Cross-Slide - 280 mm

Spindle Speeds - 11.2 rpm to 1400 rpm

Bed Width - 425 mm

Chuck Diameter - 315 mm

Spindle Bore - 60 mm

- Complete with a 3-point steady & follow-rest.

- Motorized Rapid Travels on the Carriage & Cross-Slide.

- Machine is in excellent working condition.

Video link - https://youtu.be/oogWQJBL3-w

Precision and Heavy-Duty Capability

With induction-hardened beds and rigid cast-iron construction, the TOS SU 50A / 2000 is built for exacting, heavy-duty machining. Its capacity for turning large componentsup to 2000 mm between centers and a 500 mm swing diametermakes it a trusted choice for industrial applications requiring strength, endurance, and repeatable accuracy.

User-Focused Manual Control System

This lathe features a straightforward manual control system that grants skilled machinists comprehensive control over spindle speeds and feeds. The clear, accessible design ensures user safety while delivering precision, flexibility, and ease of use when machining even complex workpieces.

Versatility Across Industrial Sectors

Manufactured for exporters, importers, and suppliers, this machine is suitable for a wide spectrum of industriesranging from general engineering to metal fabricationwhere reliability and adaptability in turning operations are essential. Its well-balanced specifications cater to both batch and bespoke production needs.

FAQs of TOS SU 50A / 2000 Heavy Duty Lathe Machine:

Q: How can the TOS SU 50A / 2000 be utilized in metalworking industries?

A: This lathe is ideal for precision turning, facing, threading, and cutting metal components in sectors such as manufacturing, repair shops, and fabrication workshops. The robust construction and wide range of spindle speeds and feeds make it suitable for a variety of metals and machining tasks.

Q: What benefits does the induction-hardened bed provide?

A: An induction-hardened bed ensures superior wear resistance and lasting alignment, preserving accuracy over long periods of heavy use. This results in reduced maintenance and consistent precision in machined parts.

Q: When is the TOS SU 50A / 2000 the right choice for your operation?

A: This lathe is a sound investment when there is a need for consistently high precision, heavy-duty turning, and handling of workpieces up to 2000 mm long and 500 mm in diameter, especially in settings where reliability and manual control are priorities.

Q: Where is this heavy-duty lathe most effectively deployed?

A: The TOS SU 50A / 2000 finds optimal use in machining workshops, manufacturing plants, and industries that demand large component turning, particularly in regions where manual machinery is favored for its simplicity and durability.

Q: What are the advantages of the manual control system?

A: The manual system grants machinists direct, tactile control over cutting operations, facilitating fine adjustments in speed and feed. This allows for flexible handling of one-off as well as repetitive tasks and is valued for its reliability and user familiarity.

Q: How do you maintain peak performance with this machine?

A: Regular lubrication, prompt replacement of worn parts, and periodic inspection of alignment and bed condition are essential. Its durable build reduces major maintenance, but following the manufacturers service schedule will ensure long-term accuracy and dependable function.
