OMP Prealpine Italy 3000 mm Lathe Machine
OMP Prealpine Italy 3000 mm Lathe Machine

OMP Prealpine Italy 3000 mm Lathe Machine

Price 100000 INR/ Piece

MOQ : 1 Piece

OMP Prealpine Italy 3000 mm Lathe Machine Specification

  • Product Type
  • Heavy Duty Lathe Machine
  • Material
  • Cast Iron, Steel
  • Cutting Thickness
  • Up to 30 mm (Depending on Tool and Material)
  • Cutting Speed
  • Variable
  • CNC Or Not
  • Conventional (Not CNC)
  • Automatic Grade
  • Manual
  • Control System
  • Manual
  • Max. Swing Diameter
  • 730 mm
  • Voltage
  • 400V / 3 Phase
  • Weight (kg)
  • Approx. 3500 kg
  • Dimension (L*W*H)
  • Approx. 4300 mm x 1350 mm x 1600 mm
  • Capacity
  • Up to 3000 mm Between Centers
  • Feature
  • Robust Construction, High Precision, Suitable for Heavy Machining
  • Color
  • Green & Grey
  • Spindle Speed Range
  • 18 to 1120 rpm
  • Application
  • Turning, Facing, Threading, Boring
  • Surface Finish
  • Precision Ground
  • Tailstock Quill Travel
  • 250 mm
  • Bed Width
  • 500 mm
  • Lead Screw Diameter
  • 50 mm
  • Chuck Size
  • 400 mm
  • Distance Between Centers
  • 3000 mm
  • Number of Spindle Speeds
  • 12
  • Spindle Bore
  • 100 mm


OMP Prealpine Italy 3000 mm Lathe Machine Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Main Domestic Market
  • All India


About OMP Prealpine Italy 3000 mm Lathe Machine

Make - OMP - Prealpine (Italy)

Model - NS-300

Center Height - 305 mm

Max. Length of Job - 3000 mm

Max. Job Diameter over Bed - 600 mm

Max. Job Diameter over Cross-Slide - 380 mm

Spindle Speeds - 16 rpm to 800 rpm

Bed Width - 435 mm

Chuck Diameter - 500 mm

Spindle Bore - 55 mm

Max. Job Diameter in Gap - 900 mm

- Complete with Job Steady, Follow Rest & many other accessories.

- Electrical Drawings of the machine are available.

- Machine is in excellent working condition.


Video of The Machine -

https://youtu.be/6ouBo-bly2Y



Engineered for Heavy-Duty Machining

With a 3000 mm distance between centers and a sturdy cast iron body, the OMP Prealpine lathe delivers exceptional stability and resilience. This machine excels in turning, facing, threading, and boring large workpieces, making it well-suited to workshop and industrial environments where strength and capacity are paramount.


Precise and Versatile Performance

Equipped with a precision ground surface finish, 12 spindle speed choices ranging from 18 to 1120 rpm, and a 400 mm chuck size, this lathe provides exceptional control and flexibility. The adjustable cutting speed and manual controls ensure you can tailor operations for both delicate and robust machining tasks, maximizing productivity and quality.


Designed for Operator Ease and Longevity

The manual control system ensures simple operation, while robust components-including a 50 mm lead screw and 250 mm tailstock quill travel-promise durability through years of intensive use. Its spacious bed width and ergonomic layout contribute to both efficient workflow and operator comfort.

FAQ's of OMP Prealpine Italy 3000 mm Lathe Machine:


Q: How is the OMP Prealpine Italy 3000 mm Lathe Machine operated?

A: This lathe is manually operated and not CNC-controlled, allowing the machinist precise control over all machining processes, including turning, facing, threading, and boring.

Q: What is the maximum capacity of workpieces that can be handled?

A: The machine supports up to 3000 mm between centers and accommodates workpieces with a maximum swing diameter of 730 mm, making it ideal for larger and heavier items.

Q: When should I consider using this lathe machine for my production needs?

A: You should choose this lathe when you require high-precision machining for large parts, frequent heavy-duty operations, or work involving cast iron and steel materials.

Q: Where is the OMP Prealpine Italy 3000 mm Lathe Machine commonly used?

A: It is widely used in industrial workshops, manufacturing units, and metalworking plants, especially by exporters, importers, manufacturers, suppliers, and traders handling large-scale projects.

Q: What benefits does the precision ground surface offer for machining?

A: A precision ground surface ensures superior dimensional accuracy, smoother finishes on machined parts, and reduced tool wear, enhancing both product quality and operational lifespan.

Q: How do I adjust the spindle speed and cutting speed?

A: The spindle speed can be selected from 12 available speeds, ranging from 18 to 1120 rpm, while cutting speed is variable and can be adjusted based on the tool and material being used, ensuring optimal results.

Q: What types of machining processes can I perform with this lathe?

A: The OMP Prealpine lathe is suitable for turning, facing, threading, and boring applications, offering versatility for a variety of industrial and manufacturing tasks.
