TOS Tool & Cutter Grinder

Get a Price/Quote

MOQ : 1 Piece

TOS Tool & Cutter Grinder Specification

Length
Machine bed length approx. 800 mm

Coating Type
No additional coating

Operation Type
Manual and Semi-Automatic

Material
Cast Iron Body, Hardened Steel Components

Cutting Force
Dependent on material and grinding wheel

Coating
Uncoated/Cast Finish

Tool Type
Universal Tool and Cutter Grinder

Shape
Rectangular Base with Vertical Grinding Column

Drill Bits Types
Can grind Twist Drills, End Mills, Reamers

Cutting Speed
Variable, typically up to 2800 RPM

Cutter Type
Tool & Cutter Grinder

Operate Method
Manual with adjustable handwheels

Machine Type
TOS Tool & Cutter Grinder

Brooches Type
Suitable for Small Broaches

Hardness
Up to 60 HRC (Depends on wheel selection)

Features
Adjustable Swivel Table, Wheel Head Movement, Multiple Attachments

Cutting Accuracy
±0.01 mm

Cutting Capacity
Max. tool diameter 250 mm, Max. tool length 230 mm

Diameter
Work table diameter approx. 150 mm

Maximum Torque
N/A (manual operated)

Processing Type
Tool Sharpening, Cutter Regrinding

Head Swivel Range
360 Degrees

Electrical
3 Phase, 415V, 50Hz

Dimensions (LxWxH)
1100 mm x 800 mm x 1350 mm

Net Weight
Approx. 750 Kg

Grinding Wheel Size
150 mm x 12.7 mm x 19 mm

Coolant System
Integrated Coolant Tray and Pump

Table Swivel Range
±45 Degrees

Applications
Regrinding and sharpening of milling cutters, drills, reamers, and various cutting tools

About TOS Tool & Cutter Grinder

Make - TOS-Kamenicek (Czech Republic)

Model - BN 102

Table Size - 140 mm x 920 mm

Max. Distance between Centers - 690 mm

Longitudinal Travel of Table - 440 mm

Cross Travel of Table - 240 mm

Vertical Travel of Grinding Spindle - 230 mm

Max. Grinding Wheel Size - 150 mm

Spindle Speeds - 2800 rpm & 5600 rpm

- Total of 3 different types of work-heads available.

- With a pair of centers for center-to-center work.

- Complete with some other accessories.

- Machine is in excellent working condition.

Video Link - https://youtu.be/nLmYAU2MdFY

Precision and Versatility in Tool Regrinding

Engineered for accuracy and reliability, the TOS Tool & Cutter Grinder supports both manual and semi-automatic operation. Its adjustable table and wheel head movement enable flexible grinding for various tool types, ensuring cutting accuracy of 0.01 mm. The machines versatility makes it suitable for twist drills, end mills, reamers, and even small broaches. With a variable cutting speed of up to 2800 RPM, users can tailor the grinding process to different materials and hardness levels.

Integrated Cooling and Ergonomic Design

The built-in coolant tray and pump maintain optimal tool temperatures during high-speed grinding, preventing thermal damage and extending tool lifespan. The rectangular base and vertical grinding column ensure stability and ease of use, while multiple attachments allow for customized setups. Ergonomic adjustable handwheels give users complete control over the grinding process, ensuring both comfort and precision in operation.

FAQs of TOS Tool & Cutter Grinder:

Q: How does the TOS Tool & Cutter Grinder improve tool sharpening precision?

A: The TOS Tool & Cutter Grinder utilizes an adjustable swivel table and 360-degree wheel head movement, which enables users to achieve a cutting accuracy of 0.01 mm. This precise setup allows for meticulous regrinding and sharpening of milling cutters, drills, reamers, and other tools.

Q: What is the maximum tool size that this grinder can handle during operation?

A: The grinder is capable of handling tools with a maximum diameter of 250 mm and a maximum length of 230 mm, making it suitable for various types and sizes of cutting implements used in manufacturing and machining.

Q: When should I use the integrated coolant system, and how does it benefit the grinding process?

A: The integrated coolant tray and pump are used during grinding operations to maintain tool temperature and prevent thermal damage. This system not only extends the life of the grinding wheel and tools but also improves surface finish and overall efficiency.

Q: Where is the TOS Tool & Cutter Grinder manufactured and who typically uses it?

A: This machine is manufactured in the Czech Republic and is widely used by exporters, importers, manufacturers, suppliers, traders, and tool shops requiring versatile and reliable tool regrinding solutions.

Q: What is the process for operating the TOS Tool & Cutter Grinder?

A: Operation involves manually positioning the tool on the work table, adjusting the swivel ranges for precise angles, and controlling the grinding wheels speed using the handwheels. The cooling system is activated during grinding for optimal results.

Q: Which types of tools and attachments are compatible with this grinder?

A: The grinder is compatible with various attachments for sharpening twist drills, end mills, reamers, and small broaches. Multiple setups and accessories are available for customized grinding needs.

Q: What are the main benefits of using the TOS Tool & Cutter Grinder for tool maintenance?

A: Primary benefits include enhanced precision, versatility for multiple tool types, improved tool lifespan due to efficient cooling, and ergonomic manual controls. The sturdy cast iron body ensures long-term durability and consistent performance.
