TOS VR4 Radial Drilling Machine

Get a Price/Quote

MOQ : 1 Piece

TOS VR4 Radial Drilling Machine Specification

Table Size
Significantly large working table

Spindle Speed
Variable

Cutting Area
Large working table area

Features
Robust construction high precision drilling

Machine Type
Radial Drilling Machine

Condition
Used

Product Type
Drilling Machine

Material
Cast iron base and arms

Computerized
No

Automatic Grade
Manual

CNC Or Not
Not CNC

Control System
Manual

Power
Electrical

Power Source
Electric

Weight (kg)
Heavy-duty not specified

Capacity
Radial drilling machine

Color
Green

Usage & Applications
Industrial drilling operations

About TOS VR4 Radial Drilling Machine

Make - TOS (Czech Republic)

Model - VR4

Drilling Capacity - 50 mm

Spindle Diameter - 75 mm

Arm Length - 1470 mm

Spindle Speeds - 45 rpm to 2000 rpm

Spindle Taper - MT4

Spindle Feed Travel - 310 mm

Vertical Travel of Arm - 650 mm

Tilting-type Heavy-Duty Table Size - 760 mm x 600 mm

Clamping Type - Manual

- Very heavy-duty tilting type cube table.

- Complete with Coolant tank & pump.

- Machine is in excellent working condition.

Video link -https://youtu.be/KStNQJD1zO0

Sturdy Design for Industrial Performance

The TOS VR4 Radial Drilling Machine boasts a solid cast iron framework that ensures long-lasting durability and stability during extensive drilling operations. Its large working table easily accommodates sizeable and heavy components, supporting a variety of industrial machining requirements. This robust machine delivers dependable results even under continuous use, making it a valuable asset for demanding workshop environments.

Efficient Manual Operation and Versatility

Operating with a manual control system, the TOS VR4 provides hands-on precision, allowing users to adjust spindle speeds and drilling conditions with accuracy. Designed for flexibility, it excels in a range of industrial applications, from basic hole drilling to complex operations on different materials. The adjustable settings and variable-speed spindle make it easy to tailor the machine for specific job tasks.

FAQs of TOS VR4 Radial Drilling Machine:

Q: How do I operate the TOS VR4 Radial Drilling Machine?

A: The TOS VR4 is operated manually, using hand controls for adjusting the spindle position, speed, and drilling depth. It requires an electrical power source to function, and the operator can change spindle speeds according to the material and drilling requirements.

Q: What types of industrial tasks can the TOS VR4 handle?

A: This machine is ideally suited for large-scale drilling operations in industrial settings. Its sizeable working table and variable spindle speed make it suitable for drilling, reaming, and boring of large, heavy workpieces typically encountered in manufacturing and fabrication plants.

Q: When should I consider using this machine over automated CNC models?

A: Choose the TOS VR4 when you need flexible, hands-on adjustment and high durability, especially for varied or custom jobs where manual control is beneficial. It is particularly suited for environments where heavy-duty, precise drilling is needed on a range of materials that may not require CNC automation.

Q: Where is the TOS VR4 Radial Drilling Machine manufactured?

A: The TOS VR4 is manufactured in the Czech Republic, a country known for its engineering and manufacturing expertise in heavy machinery.

Q: What is the process for adjusting spindle speed on the TOS VR4?

A: Spindle speed adjustment on the TOS VR4 is performed manually, allowing operators to select the appropriate speed for different materials and drilling tasks. This helps optimize drilling performance and accuracy for every job.

Q: Can the TOS VR4 accommodate heavy or bulky workpieces?

A: Yes, the machine is designed with a significantly large working table and robust cast iron construction, making it well-suited for handling and securely supporting heavy or oversized workpieces.

Q: What are the main benefits of using a manual, non-CNC radial drilling machine like this?

A: Manual machines like the TOS VR4 offer precise control and adaptability for various projects. They are cost-effective, durable, and less complex to maintain compared to CNC models, which is particularly advantageous for workshops that require versatile and reliable drilling solutions.
