Colombo-Morando Lathe Machine
Colombo-Morando Lathe Machine

Colombo-Morando Lathe Machine

MOQ : 1 Piece

Colombo-Morando Lathe Machine Specification

  • Product Type
  • Heavy Duty Lathe Machine
  • Material
  • Cast Iron Body, Hardened Steel Gears
  • Cutting Thickness
  • Up to 20 mm (depending on material)
  • Cutting Speed
  • Variable, up to 1200 RPM
  • CNC Or Not
  • Conventional (Not CNC)
  • Automatic Grade
  • Manual
  • Control System
  • Manual
  • Max. Swing Diameter
  • Up to 800 mm
  • Voltage
  • 415 V, 3 Phase, 50 Hz
  • Weight (kg)
  • Approx. 3800 kg
  • Dimension (L*W*H)
  • Approx. 4000 x 1100 x 1500 mm
  • Capacity
  • Heavy-Duty Turning Applications
  • Feature
  • Robust construction, Precision Ground Bed, High Load Capacity, Reliable Performance
  • Color
  • Industrial Grey/Blue
  • Surface Finish
  • Precision Ground and Hardened
  • Tailstock Travel
  • 200 mm
  • Feed Range
  • Longitudinal and Cross Feed Available
  • Center Distance
  • Between 1500 mm to 3000 mm (Model Dependent)
  • Chuck Diameter
  • Up to 400 mm
  • Spindle Bore
  • 100 mm
  • Bed Width
  • 600 mm
  • Spindle Speed Range
  • 35 to 1200 RPM
  • Main Motor Power
  • 7.5 HP
  • Lead Screw Diameter
  • 38 mm
  • Tool Post Type
  • 4-way Universal



About Colombo-Morando Lathe Machine

Colombo-Morando Lathe Machine

  • Make - Colombo-Morando (Italy)
  • Model - PA300
  • Center Height - 305 mm
  • Max. Length of Job - 1600 mm
  • Max. Job Diameter over Bed - 610 mm
  • Max. Job Diameter over Cross-Slide - 400 mm
  • Spindle Speeds - 24 rpm to 2400 rpm
  • Bed Width - 400 mm
  • 3-Jaw Chuck Diameter - 310 mm
  • 4-Jaw Chuck Diameter - 450 mm
  • Spindle Bore - 60 mm
  • Complete with 3-point Steady.
  • Both 3-jaw and 4-jaw chucks are available with machine.
  • Machine is in excellent working condition.

Video Link - https://youtu.be/m-ehvi3s4Zk



Engineered for Heavy-Duty Performance

With a robust cast iron construction and a hardened, precision ground bed, the Colombo-Morando Lathe Machine is built to handle intensive turning operations. Its considerable bed width and high load capacity make it ideal for large, demanding projects common in manufacturing and fabrication sectors.


Precision and Versatility in Machining

The spindle speed range of 35 to 1200 RPM and 4-way universal tool post facilitate versatile tooling setups and accurate cuts. Longitudinal and cross feeds enhance operational flexibility, allowing the machine to perform a range of turning and threading tasks efficiently.


User-Friendly and Reliable Operation

A manually operated control system ensures straightforward handling, while the manual feed system offers machinists tactile control for fine adjustments. The lathes precision surface finish minimizes friction and maximizes accuracy throughout the machining process.

FAQs of Colombo-Morando Lathe Machine:


Q: How is the Colombo-Morando Lathe Machine suited for heavy-duty applications?

A: Its cast iron body, precision ground bed, and 7.5 HP main motor are engineered to withstand large workloads, ensuring robust performance and reliability in demanding industrial environments.

Q: What types of materials can this lathe machine process?

A: The lathe can work with a wide range of materials, including steel, cast iron, aluminum, and various alloys. Its hardened steel gears and powerful drive system support high-capacity turning and cutting.

Q: When is it ideal to use a manual (conventional) lathe over CNC machines?

A: A manual lathe like this is suitable for tasks requiring operator control, custom part fabrication, prototyping, and jobs where flexibility and hands-on adjustments are essential.

Q: Where is this lathe machine typically installed and operated?

A: This machine is well-suited for manufacturing workshops, fabrication centers, and industrial repair facilities, especially where heavy-duty precision turning is routinely required.

Q: What is the process for changing spindle speed on this machine?

A: Changing spindle speed is a manual process, involving adjustment of gear levers to select from a wide speed range (351200 RPM), allowing the machinist to match the speed to the specific machining operation.

Q: How does the 4-way universal tool post benefit users?

A: The 4-way tool post enables quick tool changes and secure multi-tool setups, improving workflow efficiency and reducing downtime during complex machining processes.
