Magerle Creep Feed Surface Grinder

Get a Price/Quote

MOQ : 1 Piece

Magerle Creep Feed Surface Grinder Specification

Rotation
Clockwise/Counterclockwise

Model
Magerle

Product Type
Surface Grinder

General Use
Industrial Creep Feed Surface Grinding

Material
Cast Iron

Capacity
Heavy Duty

Weight (kg)
3200 kg

Computerized
No

Automatic
Semi-Automatic

CNC Or Not
Not CNC

Control System
Manual

Table Size
240 mm x 750 mm

Table Slide Way
Box Type Hardened Way

Magnetic Chuck Size
200 mm x 700 mm

Grinding Wheel Size
400 mm x 50 mm x 127 mm

Grinding Wheel Speed
1450 RPM

Grinding Length
650 mm

Floor Space
1800 mm x 1500 mm

Fuel Tank Capacity
60 Liters

Spindle Speed
1450 RPM

Power
7.5 HP

Voltage
415 V

Dimension (L*W*H)
2400 mm x 1500 mm x 1800 mm

Feature
Precision Surface Finishing

Color
Blue & White

Chuck Flatness Accuracy
0.002 mm

Coolant System
Available

Table Load Capacity
400 kg

Lubrication System
Automatic

Application
Mould, Die and Tool Room/Automotive/Aerospace

Main Motor Drive
Direct Coupling

Vertical Feed
Manual/Auto

Cross Feed
Manual/Auto

About Magerle Creep Feed Surface Grinder

Magerle Creep Feed Surface Grinder

Make - Magerle (Switzerland)
Model - FPA7
Table Size - 240 mm x 750 mm
Longitudinal Travel - 700 mm
Cross Travel - 270 mm
Max. Working Height - 365 mm
Plunge Travel - 390 mm
Max. Wheel Size - 400 mm x 120 mm Width
Equipped with hydraulic creep-feed.
Complete with coolant filtration unit.
Operating Manual, electrical drawings etc. available.
Machine is in excellent condition.

Precision Engineering for Demanding Applications

The Magerle Creep Feed Surface Grinder stands out for its meticulous surface finishing, designed specifically for high-precision uses in mould, die, tool room, automotive, and aerospace industries. Its robust construction and advanced features enable consistently accurate and repeatable grinding, making it ideal for critical industrial workflows.

Versatile Semi-Automatic Operation

Offering both manual and auto controls for vertical and cross feed movements, this grinder provides flexibility for diverse operational needs. The semi-automatic design allows operators to tailor the grinding process, balancing manual expertise with automated precision for optimum results.

Heavy-Duty Capacity and Advanced Systems

With a heavy-duty table load capacity of up to 400 kg and a massive, stable cast iron frame, the machine ensures stability even during intensive operations. The automatic lubrication and advanced coolant systems further enhance machine lifespan and workpiece quality, supporting extended production runs.

FAQs of Magerle Creep Feed Surface Grinder:

Q: How does the Magerle Creep Feed Surface Grinder benefit industrial users?

A: The grinder delivers high-precision surface finishing with 0.002 mm accuracy, essential for demanding industries like aerospace, die, and automotive. Its heavy-duty load capacity, robust construction, and automated systems contribute to increased productivity, reliability, and longevity in industrial settings.

Q: What process does the machine use for creep feed grinding?

A: Creep feed grinding involves a slow, deep cut with a large contact area between the grinding wheel and the workpiece. This process, enabled by the Magerles powerful 7.5 HP direct-coupled motor and 1450 RPM spindle, ensures efficient material removal and finer surface finishes in a single pass.

Q: When should I use manual versus automatic feed options?

A: Manual feed is ideal for tasks requiring operator precision and adjustments, such as custom or initial setups. Automatic feed is preferable for repetitive or high-volume operations, providing consistent feeds and freeing operators to focus on quality control and efficiency.

Q: Where is the Magerle Surface Grinder commonly utilized?

A: This grinder is widely used in mould, die, and tool rooms, as well as in automotive and aerospace manufacturing environments. Its versatility and accuracy make it suitable for high-precision and heavy-duty surface grinding tasks across these industries.

Q: What are the usage steps for optimal grinding performance?

A: Install the workpiece onto the magnetic chuck, select the desired grinding wheel speed (1450 RPM), use the coolant and automatic lubrication systems, and adjust feeds as per the work requirement. Always follow safety protocols and manufacturer guidelines for setup, operation, and shutdown.

Q: What maintenance is required for the lubrication and coolant systems?

A: The automatic lubrication system delivers regular lubrication to critical components, minimizing manual intervention. Regularly check lubricant and coolant levels (fuel tank 60 liters) and follow scheduled maintenance for peak machine performance and extended life span.

Q: How does the design support heavy-duty grinding?

A: The cast iron body, hardened box slide ways, and 3200 kg weight provide high rigidity and vibration resistance, ensuring precision even under demanding loads. The machines large table and magnetic chuck accommodate substantial workpieces for versatile applications.
