TOS HO-63 Heavy Duty Horizontal Shaper Machine

Name: TOS HO-63 Heavy Duty Horizontal Shaper Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000.00 INR
Availability: InStock

Price 100000.00 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS HO-63 Heavy Duty Horizontal Shaper Machine Specification

Noise Level
Below 75 dB

Machine Type
Horizontal Shaping Machine

Control System
Manual with Mechanical Feed

Lubricating System
Centralized Lubrication

Frequency
60 Hertz (HZ)

Power Rating
5.5 kW

Drive
Mechanical

Features
Rigid Construction, Vibration Free, Interchangeable Tools

Accuracy
High, ±0.01 mm

Model No
HO-63

Voltage
220 Volt (v)

Operating Temperature
5°C to 45°C

Production Capacity
Large Batch Production

Motor Power
7.5 HP

Frame Type
Heavy Duty, Rigid

Cooling System
Inbuilt Coolant Pump

Product Type
Horizontal Shaper Machine

Technology
Conventional Machining

Power Source
Electricity

Operating Type
Semi Automatic

Power
7.5 HP

Surface Treatment
Paint Coated

Dimension (L*W*H)
2500 mm x 1200 mm x 1700 mm

Weight (kg)
4200 kg

Color
Standard Green

Usage & Applications
Heavy Duty Metal Shaping, Planing, Engineering Workshops

Table Travel (Cross)
650 mm

Maximum Shaping Length
630 mm

Ram Travel
710 mm

Floor Space Required
Approx. 12 sq.m.

Main Spindle Speed
Variable, Mechanical Shift

Accessories Supplied
Standard Tools Set, Operating Manual

Table Size (L x W)
700 mm x 355 mm

Working Speed
30-170 Strokes/Minute (Adjustable)

Table Travel (Vertical)
360 mm

Tool Head Swivel
60°

Ram Adjustment
195 mm

Max Distance Between Table and Ram
370 mm

Tool Clamping
Quick Release

TOS HO-63 Heavy Duty Horizontal Shaper Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS HO-63 Heavy Duty Horizontal Shaper Machine

Make - TOS (Czech Republic)

Model - HO-63

Max. Stroke Length - 630 mm

Table Size - 630 mm x 400 mm

Stroke Rate - 11 strokes/min to 125 strokes/min

Feed Travel Rate - 0 mm/stroke to 4 mm/stroke

- Automatic Downward Feed Travel of the Tool Post.

- Motorised Rapid Travels on Cross & Vertical Movement of Table.

- Complete with Clamping Vice.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/fPU1gvr6P0w

Advanced Performance and Durability

The TOS HO-63 features a heavy-duty, rigid frame and vibration-free construction, ensuring stability and consistent operation. Its robust mechanical drive and interchangeable tools make it ideal for rigorous engineering tasks. With high precision and centralized lubrication, maintenance is simple and machine lifespan is extended.

Versatile Applications

Engineered for a variety of metalworking needs, the machine caters to large batch production and is widely used in workshops, manufacturing units, and planing operations. The adjustable speed, sizable worktable, and quick-release clamping support a range of workpiece sizes and complex shaping tasks.

Operator-Focused Design

Safety and convenience are integral to the HO-63. The semi-automatic operation, manual control system, and ergonomic tool head swivel ensure ease of use. Alongside its inbuilt coolant pump and low noise output, this shaper enhances productivity while maintaining a comfortable workspace.

FAQ's of TOS HO-63 Heavy Duty Horizontal Shaper Machine:

Q: How does the TOS HO-63 shaper machine achieve high shaping precision?

A: The HO-63 provides high-accuracy metal shaping (0.01 mm) through its rigid frame, smooth mechanical feed, and precise control system, making it suitable for applications where exact tolerances are required.

Q: What types of metals and workpieces can be shaped using this machine?

A: This horizontal shaping machine can process a variety of metals, including steel, aluminum, and cast iron, and is suitable for components requiring intricate profiles, slots, and surfaces in heavy-duty production settings.

Q: When is it beneficial to use the TOS HO-63 for batch production?

A: The HO-63 is ideal for large batch production when consistent accuracy, rapid tool changes, and high output are essential, particularly in engineering workshops and manufacturing facilities.

Q: Where should the machine be installed for optimal performance?

A: It is recommended to install the machine in a well-ventilated area with adequate floor space (approx. 12 sq.m.) and access to a stable power supply (220 V, 60 Hz), ensuring safety, efficiency, and ease of operation.

Q: What is the process for adjusting the ram and table travel?

A: Ram travel and adjustment (up to 710 mm and 195 mm respectively) as well as table movements (vertical: 360 mm; cross: 650 mm) can be fine-tuned manually using the machine's control levers for flexible handling of different workpiece dimensions.

Q: How does the quick-release tool clamping benefit users?

A: The quick-release mechanism allows for swift and secure tool changes, minimizing setup time and enhancing productivity, which is particularly useful during complex or repetitive shaping operations.

Q: What built-in features support reliable and safe operation of the TOS HO-63?

A: The machine offers a centralized lubrication system, inbuilt coolant pump, vibration-free construction, and operates with noise levels below 75 dB, all contributing to reliable performance, extended machine life, and operator safety.
